home > product> solutions > pac > LinPAC > LinPAC Selection Guide





Will be available
Available soon
Will be phased out
Phased out
Standard LinPAC(Linux Kernel Inside)
The controller supports following software development tools:
1. SDK for Linux environment
2. SDK for Windows environment
Model OS Pre-Installed Software CPU Flash SDRAM Ethernet VGA Resolution USB I/O Slot Audio Port
LP-2241 Linux Kernel 3.2.14 None AM3354, 1 GHz 512 MB 512 MB 2 1024 x 768 2 I/O expansion board optional
(Note 2)		 None

LP-5131 Linux kernel 2.6 None PXA270,
520 MHz		 64 MB 128 MB 1 800 x 600 2 I/O expansion board optional
(Note 1)		 None
LP-5131-OD Yes
LP-5141 2 1 None
LP-5141-OD Yes
  LP-5231 Linux kernel 3.2.14 None AM3354, 1 GHz 512 MB 512 MB 1 1024 x 768 1 I/O expansion board optional
(Note 2)		 None
LP-5231M Linux kernel 3.2.14 None AM3354, 1 GHz 512 MB 512 MB 1 1024 x 768 1 I/O expansion board optional
(Note 2)		 None

LP-5231PM-3GWA Linux kernel 3.2.14 None AM3354, 1 GHz 512 MB 512 MB 1 1024 x 768 1 I/O expansion board optional
(Note 2)		 None

LP-5231PM-4GE
LP-5231PM-4GC		 Linux kernel 3.2.14 None AM3354, 1 GHz 512 MB 512 MB 1 1024 x 768 1 I/O expansion board optional
(Note 2)		 None

LP-8131 Linux kernel 2.6 None PXA270
520 MHz		 128 MB 128 MB 2 1024 x 768 2 1 None
LP-8431 4
LP-8831 8

  LP-8141 Linux kernel 2.6 None PXA270
520 MHz		 96 MB 128 MB 2 800 x 600 1 1 None
  LP-8441 4
  LP-8841 8

LP-8081 Linux kernel 2.6 None LX 800
500 MHz		 4 GB 1 GB DDR SDRAM 2 1024 x 768 2 0 None
LP-8381 3
LP-8781 7

LP-8181-Atom Linux kernel 2.6 None Atom
1.33 GHz		 8 GB 1 GB DDR SDRAM 2 1024 x 768 4 1 None
LP-8381-Atom 3
LP-8781-Atom 7

LP-8121 Linux kernel 3.2.14 None Cortex-A8
1.0 GHz		 512 MB 512 MB DDR3 2 1024 x 768 2 1 None
LP-8421 4
LP-8821 8
Note 1: The I/O Expansion Bus can mount one XW-board only.
Note 2: The I/O Expansion Bus can mount one XV-board only.
TOP | HOME


Will be available
Available soon
Will be phased out
Phased out
Standard LinPAC(Linux Kernel Inside)
The controller supports following software development tools:
1. SDK for Linux environment
2. SDK for Windows environment
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution Ethernet Port RS-232/485 I/O Slot
LX-8031 Linux kernel 3.2 None X86
1.0 GHz,
dual core		 32 GB 2 GB DDR SDRAM 1024 x 768 2 5 0
LX-8131 4 1
LX-8331 3
LX-8731 7
TOP | HOME


Will be available
Available soon
Will be phased out
Phased out
Standard LinPAC(Linux Kernel Inside)
The controller supports following software development tools:
1. SDK for Linux environment
2. SDK for Windows environment
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution Ethernet Port RS-232/485 I/O Slot
LP-9221 Linux kernel 3.2.14 None Cortex-A8,
1.0 GHz		 512 MB 512 MB DDR3 1024 x 768 2 4 2
LP-9421 4
LP-9821 8
TOP | HOME


Will be available
Available soon
Will be phased out
Phased out
Standard LinPAC(Linux Kernel Inside)
The controller supports following software development tools:
1. SDK for Linux environment
2. SDK for Windows environment
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution Ethernet Port RS-232/485 I/O Slot
LX-9171 Linux kernel 4.14.12 None E3827
1.75 GHz, dual core		 32 GB 2 GB DDR3 1920 x 1080 2 4 1
LX-9371 3
LX-9771 7

LX-9181 Linux kernel 4.14.12 None E3845
1.91 GHz, quad core		 32 GB 4 GB DDR3 1920 x 1080 2 4 1
LX-9381 3
LX-9781 7
