Linux driver for I-7565-H1 / I-7565-H2 is available now !! |
|
|
|
|
|
 |
|
|
|
|
|
Recently, Linux has been the platform of choice in lots industrial applications because of its stability, open source, and free of charge. ICP DAS, one of a leading industrial applications providers announces I-7565-H1 / I-7565-H2 now support for Linux based on Linux kernel 2.6 with PC and LinPAC series controller platforms. Users can apply I-7565-H1 / I-7565-H2 on Linux system to implement various CAN bus applications. |
|
|
|
|
|
Linux distributions: |
|
|
Linux kernel version of distributions |
Linux kernel Distribution |
2.6.x |
Debian GUN/Linux |
4.0 |
Fedora Core |
2/3/4/5/6/7/8 |
Mandrake(Mandriva) |
10.0/10.1/10.2 |
Red Hat Enterprise |
4/5 |
Ubuntu |
7.04 |
SUSE |
9.1/9.2/9.3/10.0 |
LinPAC Series |
Linux kernel 2.6 |
|
|
|
|
|
|
|
|
|
ICP DAS CAN bus Converters Comparison Table : |
|
|
|
I-7565-H1 |
I-7565-H2 |
I-7565 |
I-7540D |
I-7530 |
I-7530A |
Built-in CPU |
32-bit CPU
72M Hz |
32-bit CPU
72M Hz |
8-bit CPU
20MHz |
16-bit CPU
80M Hz |
8-bit CPU
20MHz |
8-bit CPU
20MHz |
Comm. Interface |
USB |
USB |
USB |
Ethernet |
RS232 |
RS232/422/485 |
CAN Channel |
1 |
2 |
1 |
1 |
1 |
1 |
Signal Isolation |
2500 Vrms |
2500 Vrms |
2500 Vrms |
2500 Vrms |
2500 Vrms |
2500 Vrms |
DC/DC
Isolation |
3000 VDC |
3000 VDC |
3000 VDC |
1000 VDC |
3000 VDC |
3000 VDC |
CAN Controller |
CPU Built-in |
CPU Built-in |
CPU Built-in |
SJA1000 |
CPU Built-in |
CPU Built-in |
CAN Transceiver |
82C250 |
82C250 |
82C250 |
82C250 |
82C250 |
82C250 |
UART FIFO |
100 |
100 |
900 |
1000 |
900 |
900 |
CAN FIFO |
256 |
128 |
1000 |
1000 |
1000 |
1000 |
Max FPS (1Mbps) |
3000 |
3000 |
300 |
1500 |
300 |
300 |
CAN baud rate |
5k ~ 1M
User-defined
|
5k ~ 1M
User-defined |
10k ~ 1M |
10k ~ 1M
User-defined |
10k ~ 1M |
10k ~ 1M |
Suitable Protocol |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
Driver Support |
Win2K/XP/Linux |
Win2K/XP/Linux |
Win2K/XP/Linux |
Win2K/XP/CE/Linux |
Win2K/XP/CE/Linux |
Win2K/XP/CE/Linux |
Power Supply |
USB |
USB |
USB |
10 ~ 30 VDC
|
10 ~ 30 VDC
|
10 ~ 30 VDC
|
|
|
|
|
|
|
Datasheet Download: http://ftp.icpdas.com/pub/cd/fieldbus_cd/can/converter/i-7565-h1h2/manual/linux/i-7565h1h2-linux-manual_v1.0.pdf
For more information, please refer to: http://www.icpdas.com/products/Remote_IO/can_bus/i-7565-H1H2.htm
Related Product: http://www.icpdas.com/products/Remote_IO/can_bus/can_intro.htm |
|
|
|
|
|
|
 |
