Standard WP-5000 (Windows CE .NET 5.0/7.0 Inside)
The controller supports the following software development tools:
1. DLLs of I/O modules for VS.Net 2008
2. DLLs of Modbus/RTU and Modbus/TCP for VS.Net 2008
Model OS Pre-Installed Software CPU Flash SDRAM Ethernet VGA Resolution Wireless Communication RS-232/
485		 I/O Expansion Bus Audio Port
  WP-5231-CE7 CE 7.0 – Cortex-A8, 1GHz 256 MB DDR3 x 512 MB 1 640 x 480
800 x 480
800 x 600
1024 x 768 		– 2/2 Yes(Note1) –
WP-5231M-CE7
  WP-5231PM-3GWA-CE7 3G (WCDMA) 1/2
WP-5231PM-4GE-CE7
WP-5231PM-4GC-CE7		 4G (LTE)

  WP-5141 CE 5.0 – PXA270, 520 MHz 64 MB 128 MB 2 800 x 600 – 2/1 Yes(Note2) –
  WP-5141-OD Yes
WP-5151 1/2 –
WP-5151-OD Yes
Note:
(1) The I/O Expansion Bus can mount one XV-board only.
(2) The I/O Expansion Bus can mount one XW-board only.
TOP | HOME

Will be available
Available soon
Will be phased out
Phased out
InduSoft Based WP-5000 (Windows CE .NET 5.0/7.0 Inside)
The controller can be used to develop following applications:
1. Human Machine Interfaces (HMI)
2. Supervisory Control and Data Acquisition System (SCADA)
3. Web server
Model OS Pre-Installed Software CPU Flash SDRAM Ethernet VGA Resolution Wireless Communication RS-232/
485		 I/O Expansion Bus Audio Port
WP-5239-CE7 CE 7.0 InduSoft Cortex A8, 1 GHz 256 MB DDR3 x 512 MB 1 640 x 480
800 x 480
800 x 600
1024 x 768 		– 2/2 Yes(Note1) –

WP-5149 CE 5.0 InduSoft PXA270, 520 MHz 64 MB 128 MB 2 800 x 600 – 2/1 Yes(Note2) –
WP-5149-OD Yes
Note:
(1) The I/O Expansion Bus can mount one XV-board only.
(2) The I/O Expansion Bus can mount one XW-board only.

Will be available
Available soon
Will be phased out
Phased out
Win-GRAF Based WP-5000 (Windows CE .NET 7.0 Inside)
The controller fully supports all five of the IEC61131-3 standard PLC languages:
1. Ladder diagram
2. Function block diagram
3. Sequential function chart
4. Structured text
5. Instruction List
It supports Modbus protocol and can link to distributed I/O modules with Modbus or DCON protocol via the RS-232/485 or Ethernet.
Model OS Pre-Installed Software CPU Flash SDRAM Ethernet VGA Resolution Wireless Communication RS-232/
485		 I/O Expansion Bus Audio Port
  WP-5238-CE7 CE 7.0 Win-GRAF Cortex A8, 1 GHz 256 MB DDR3 x 512 MB 1 640 x 480
800 x 480
800 x 600
1024 x 768 		– 2/2 Yes (Note) –
Note: The I/O Expansion Bus can mount one XV-board only.

Will be available
Available soon
Will be phased out
Phased out
ISaGRAF Based WP-5000 (Windows CE .NET 5.0 Inside)
The controller fully supports all five of the IEC61131-3 standard PLC languages:
1. Ladder diagram
2. Function block diagram
3. Sequential function chart
4. Structured text
5. Instruction List plus flow chart
It supports Modbus protocol and can link to distributed I/O modules with Modbus or DCON protocol via the RS-232/485 or Ethernet.
Model OS Pre-Installed Software CPU Flash SDRAM Ethernet VGA Resolution Wireless Communication RS-232/
485		 I/O Expansion Bus Audio Port
WP-5147 CE 5.0 ISaGRAF PXA270, 520 MHz 64 MB 128 MB 2 800 x 600 – 2/1 Yes(Note) –
WP-5147-OD Yes
Note: The I/O Expansion Bus can mount one XW-board only.

Will be available
Available soon
Will be phased out
Phased out
ISaGRAF & InduSoft Based WP-5000 (Windows CE .NET 5.0 Inside)
The controller includes features of ISaGRAF and InduSoft.
Model OS Pre-Installed Software CPU Flash SDRAM Ethernet VGA Resolution Wireless Communication RS-232/
485		 I/O Expansion Bus Audio Port
WP-5146 CE 5.0 ISaGRAF & InduSoft PXA270, 520 MHz 64 MB 128 MB 2 800 x 600 – 2/1 Yes(Note) –
WP-5146-OD Yes
Note: The I/O Expansion Bus can mount one XW-board only.
