WP-5231PM-3GWA-CE7

~ NEW ~


Model: WP-5231PM-3GWA-CE7

  • Cortex-A8, 1GHz CPU
  • Windows CE 7.0 Professional
  • 512 MB SDRAM and 256 MB Flash
  • 64-bit Hardware Serial Number
  • Hard Real-Time Capability
  • I/O Expansion Bus
  • 10/100/1000M Ethernet Ports
  • 3 Serial Ports (RS-232/485)
  • Operating Temperature: -25 ~ +75°C
  • Industrial Tri-band 3G module
  • 3G modem

The WP-5231PM-3GWA-CE7 is equipped a Cortex-A8 CPU (1GHz) and running a windows CE 7.0 operating system. The optional I/O expansion board, XV-board, provides high-protection I/O. Using the built-in Flash and microSD, the WP-5231PM-3GWA-CE7 can save application program, image file and data.

The 3G module work on frequencies of WCDMA 2100/1900/900/850 MHz and GSM 850/900/1800/1900 MHz. These modules utilize the 3G network for convenient and inexpensive data transfer from remote instruments, meters, computers or control systems in either live data or packet data. These modules has the integrated TCP/IP stack so that even simple controllers with serial communications ports can be connected to the modem without the need for special driver implementation. With the features of theirs, the systems can be SMS and GPRS or 3G connection applications with our PAC.

Windows CE 7.0 is a compact and real-time OS used to quickly create time critical and high performance applications. Using Windows CE 7.0 gives an ability to run PC-based control software such as Visual Basic .NET, Virtual C#.
★ FTP Server
★ Web Server
★ SQL Compact Edition 3.5		 ★ .NET Compact Framework 3.5
★ Virtual CE Pro (VCEP)
★ OPC Server (NAPOPC_CE5 DA Server))


System Software
OS Windows CE 7.0 Professional
.Net Compact Framework 3.5
Embedded Service FTP server, Web server
SDK Provided Dll for Visual Studio.Net 2008
Multilanguage Support English, German, French, Spanish, Russian, Italian, Korean, Simplified Chinese, Traditional Chinese
CPU Module
CPU Cortex-A8, 1GHz
DDR3 SDRAM 512 MB
Flash 256 MB
FRAM 64 KB
Expansion Flash Memory microSD socket with one microSD card (support up to 32 GB microSDHC card)
RTC (Real Time Clock) Provide second, minute, hour, date, day of week, month, year
64-bit Hardware Serial Number Yes, for Software Copy Protection
Dual Watchdog Timers Yes
LED Indicators 1 LED for Power and Running; 2 LED for user defined
Rotary Switch Yes (0 ~ 9)
VGA & Communication Ports
VGA and Communication Ports 640 × 480, 800 × 480, 800 × 600, 1024 × 768
Ethernet RJ-45 x 1, 10/100/1000 Based-TX ( Auto-negotiating, Auto MDI/MDI-X, LED indicators)
USB 2.0 (host) 1
COM 1 Console Reserved for OS
COM 2 RS-232 (RxD, TxD and GND); Non-isolated
COM 3 RS-485 (Data+, Data-); Non-isolated
COM 4 RS-485 (Data+, Data-); 2500 VDC isolated
I/O Expansion Slots
I/O Expansion Bus Yes, one optional XV-board
Mechanical
Casing Metal
Dimensions (W x L x H) 117 mm x 126 mm x 58 mm
Installation DIN-Rail Mounting/Wall Mounting
Environmental
Operating Temperature -25 to +75°C
Storage Temperature -40 to +80°C
Ambient Relative Humidity 10 to 90% RH (non-condensing)
Power
Input Range +12 to +48 VDC
Consumption 6.5 W
GSM System
Frequency Band GSM: 850/900/1800/1900 MHz
GPRS Connectivity GPRS class 12/10; GPRS station class B
Data GPRS Downlink transfer: Max. 85.6 kbps; Uplink transfer: Max 42.8k bps
3G System
Frequency Band WCDMA 850/900/1900/2100 MHz
Data Transmission WCDMA / HSPA+, Download: Max. 14.4Mbps; Upload: Max 5.76Mbps
GPS System (option)
Support Channels 32
Protocol Support NMEA 0183

WP-5231PM-3GWA-CE7 CR PAC with WinCE 7.0、one LAN port、GPS and 3G module (WCDMA) (Metal Case) (RoHS)

XV-Board Add-on I/O Expansion Board
