發佈I-7565-H1/I-7565-H2的Linux 驅動程式 |
|
|
|
|
|
 |
|
|
|
|
|
由於Linux系統高穩定性、開放原始碼及自由傳播特性，近年來Linux在工業應用環境越來越受到重視。而ICP DAS已在Linux領域耕耘多年，從Kernel 2.2.x, 2.4.x到2.6.x提供完整工業級Linux解決方案，讓使用者可於Linux系統上搭配泓格的I-7565-H1/I-7565-H2的轉換器來開發各種CAN bus的應用系統。 |
|
|
|
|
|
可使用的Linux分發版本 |
|
|
| 常見Linux分發版本所使用的核心版本 |
| Linux核心版本套件版本 |
2.6.x |
| Debian GUN/Linux |
4.0 |
| Fedora Core |
2/3/4/5/6/7/8 |
| Mandrake(Mandriva) |
10.0/10.1/10.2 |
| Red Hat Enterprise |
4/5 |
| Ubuntu |
7.04 |
| SUSE |
9.1/9.2/9.3/10.0 |
| LinPAC Series |
Linux kernel 2.6 |
|
|
|
|
|
|
|
|
|
泓格各種介面CAN bus轉換器產品比較表 : |
|
|
| |
I-7565-H1 |
I-7565-H2 |
I-7565 |
I-7540D |
I-7530 |
I-7530A |
| 內建CPU |
32-bit CPU
72M Hz |
32-bit CPU
72M Hz |
8-bit CPU
20MHz |
16-bit CPU
80M Hz |
8-bit CPU
20MHz |
8-bit CPU
20MHz |
| 通訊介面 |
USB |
USB |
USB |
Ethernet |
RS232 |
RS232/422/485 |
| CAN通道 |
1 |
2 |
1 |
1 |
1 |
1 |
| 訊號隔離 |
2500 Vrms |
2500 Vrms |
2500 Vrms |
2500 Vrms |
2500 Vrms |
2500 Vrms |
| 電源隔離 |
3000 VDC |
3000 VDC |
3000 VDC |
1000 VDC |
3000 VDC |
3000 VDC |
| CAN控制器 |
CPU Built-in |
CPU Built-in |
CPU Built-in |
SJA1000 |
CPU Built-in |
CPU Built-in |
| CAN收發器 |
82C250 |
82C250 |
82C250 |
82C250 |
82C250 |
82C250 |
| UART緩衝區 |
100 |
100 |
900 |
1000 |
900 |
900 |
| CAN緩衝區 |
256 |
128 |
1000 |
1000 |
1000 |
1000 |
| 最大FPS (1Mbps) |
3000 |
3000 |
300 |
1500 |
300 |
300 |
| CAN鮑率 |
5k ~ 1M
User-defined |
5k ~ 1M
User-defined |
10k ~ 1M |
10k ~ 1M
User-defined |
10k ~ 1M |
10k ~ 1M |
| 適合的CAN Protocol |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
CANopen,
DeviceNet J1939 |
| Driver支援 |
Win2K/XP/Linux |
Win2K/XP/Linux |
Win2K/XP/Linux |
Win2K/XP/CE/Linux |
Win2K/XP/CE/Linux |
Win2K/XP/CE/Linux |
| 電源供應 |
USB |
USB |
USB |
10 ~ 30 VDC
|
10 ~ 30 VDC
|
10 ~ 30 VDC
|
|
|
|
|
|
|
Datasheet下載連結: http://ftp.icpdas.com/pub/cd/fieldbus_cd/can/converter/i-7565-h1h2/manual/linux/i-7565h1h2-linux-manual_v1.0.pdf
更進一步的訊息請參考: http://www.icpdas.com/products/Remote_IO/can_bus/i-7565-H1H2.htm
CAN bus相關產品: http://www.icpdas.com/products/Remote_IO/can_bus/can_intro.htm |
|
|
|
|
|
|
 |
