Antenna with SMA Plug
|
|||||
| Model | Employment | Radiation | Band | Gain(dBi) | Note |
|---|---|---|---|---|---|
| ANT-104-01 | RFU-400 Products | Omni-Directional | 420 ~ 440 MHz | 0 | Dipole |
| ANT-421-02 | G-4500 Series, GTM-201, GT-500, I-8212W, I-8213W Products |
824 ~ 960 MHz 1710 ~ 2170 MHz |
-0.9 ± 0.7 dBi @890 MHz +1.7 ± 0.7 dBi @1930 MHz |
||
| ANT-421-04 | 4G Products | 704~960 MHz 1710~2170 MHz 2500-2690 MHz |
1 dBi @ 704~960 MHz 2~2.5 dBi @ 1710~2170 MHz 2.5 dBi @ 2500~2690 MHz |
||
| ANT-421-05 | 4G Products | 698~960 MHz 1710~2110 MHz 2310~2690 MHz |
1.5 dBi @ 698~960 MHz 4.0 dBi @ 1710~2110 MHz 5.0 dBi @ 2110~2500 MHz 3.5 dBi @ 2500~2690 MHz |
||
| ANT-859-01 | 4G/5G Products | 617~798 MHz 803~960 MHz 1166‐1610 MHz 1710‐2200 MHz 2300‐2690 MHz 3300‐3800 MHz 4200‐5000 MHz 5150‐5925 MHz |
1.04 dBi @ 617~798 MHz 0.74 dBi @ 803~960 MHz 2.31 dBi @ 1166‐1610 MHz 3.58 dBi @ 1710‐2200 MHz 3.88 dBi @ 2300‐2690 MHz 2.26 dBi @ 3300‐3800 MHz 4.5 dBi @ 4200‐5000 MHz 4.31 dBi @ 5150‐5925 MHz |
||
ANT-Base-01  |
3G/4G Products | - | 3G/4G Band | - | Magnetic mount base |
| ANT-115-03 | GPS Products | Directional | GPS: 1575.42±1.023 MHz | 2 ~ 3 dBi | Magnetic mount antenna |
| ANT-115-03-1 | GPS: 1575.42±5 MHz | 4.5 dBi | |||
ANT-115-03-2  |
GPS/Glonass Products | GPS: 1575.42±5 MHz Glonass: 1610±8 MHz |
|||
ANT-115-P1  |
GTM-205M, GRP-2841M Products | GPS: 1575.42±1.023 MHz | 5 dBi | ||
| SST-2450 | ZB-2000-T | ZB-2000-PA | ZT-2000 | WF-2000 | |
|---|---|---|---|---|---|
| ANT-124-03 | 300 m |
100 m |
None | None | 40 m |
| ANT-124-05 | 350 m | 115 m | 700 m |
700 m |
50 m |
| ANT-8 | 550 m | 180 m | 1000 m | 1000 m | - |
| ANT-15 | 1100 m | 360 m | 2000 m | 2000 m | - |
| ANT-18 | 1400 m | 450 m | 2560 m | 2560 m | - |
| ※ These values represent the average LOS (Line of Sight) transmission range and are based on an elevation of three meters ※ Transmission range values should only be used as a reference and should be adjusted accordingly depending on the actual environment |
|||||
|
|
|||||
|
Antenna with RP-SMA Plug
|
|||||
| Model | Employment | Radiation | Band | Gain(dBi) | Note |
|---|---|---|---|---|---|
| ANT-18 | SST-2450, ZigBee, 2.4 GHz Products |
Directional | 2.4 ~ 2.5 GHz | 18 | Panel |
| ANT-15 | Omni-Directional | 15 | Dipole | ||
| ANT-8 | 8 | ||||
| ANT-124-05 | SST-2450, ZigBee, WF-2000, 2.4 GHz Products |
5 | |||
| ANT-124-03 | 3 | ||||
| ANT-104-02 | RFU-433 Products | 420 ~ 440 MHz | 0 | ||
| ANT-109-01 | RFU-900 Products | 824 ~ 960 MHz | 2.0 ± 0.7 dBi @ 900 MHz | ||
ANT-Base-02  |
SST-2450, ZigBee, 2.4 GHz, RFU-433 and RFU-900 Products |
- | 2.4 GHz | - | Magnetic mount base |
