ANT-421-05
5 dBi, 4G LTE omni-directional antenna (SMA Male Plug)
Features
- 2G GSM/GPRS Antenna (850/900/1800/1900 MHz)
- 3G WCDMA Antenna (850/1900/2100 MHz)
- 4G LTE Antenna (800/850/900/1800/2100/2600 MHz)
- SMA Male (Plug)
- Omni-Directional
Introduction
Applications
Ordering Information
| PRODUCT SERIES | DESCRIPTION | QNT. | INQUIRY |
|---|---|---|---|
This combination include other products.
Similar Products
| Mechanical | |
|---|---|
| Dimensions (mm) | 207 mm x 13 mm |
| Weight | 32.5 ± 2 g |
| Environment | |
|---|---|
| Operating Temperature | -30 °C ~ +80 °C |
| Storage Temperature | -30 °C ~ +85 °C |
| Antenna | |
|---|---|
| Type | Dipole |
| Connector | SMA Male (Plug) |
| Gain (dBi) | 1.5 dBi @ 698~960 MHz 4.0 dBi @ 1710~2110 MHz 5.0 dBi @ 2110~2500 MHz 3.5 dBi @ 2500~2690 MHz |
| Band | 698~960MHz 1710~2110MHz 2310~2690MHz |
