Integrated display and control pane
The main control unit of ICPCON 8000 family has an integrated control panel providing a Simple Man Machine Interface S-MMI) to the 8000 unit. The S-MMI includes a Five digit 7-SEG display, LED indicator and push buttons for selecting various configurations and modes of operation. The 7-seg display on S-MMI is used to show the status and values of the analog inputs. (The status of the digital I/O is displayed on the front of the module) .

Push Button Keys
There are four push buttons on the front panel. These are Up, Down, Mode, Set and are designed for general-purpose applications. They can be used to change the system configuration and the mode of operation .

Front Panel LEDS
The 3 LEDs, L1,L2,L3, are designed for general-purpose applications.

User Memory and Data Storage
When the 8000 is used as an autonomous controller using an embedded application, various options of users memory and data storage can be chosen. Up to 32 Mbytes of data storage is available using flash ROM, in addition 512K bytes of battery backed up SRAM is available for data and or program storage

Embedded software protection
Great attention has been given to providing protection to embedded OEM application software. Each 8000 is supplied with a unique electronic serial number which can be checked by the application software. In addition an ASICkey can be installed in the unit. Each ASICkey can be uniquely programed to provide a high degree of protection for illegal copying
