WinPAC-8000-CE7 Series (Win-GRAF based)
WP-8128-CE7, WP-8428-CE7, WP-8828-CE7 |
|
| |
|
| ~ New ~ |
|
|
|
| |
 |
| |
● |
Cortex-A8, 1GHz CPU |
| |
● |
512 MB DDR3 and 256 MB Flash |
| |
● |
Windows CE 7.0 Professional |
| |
● |
Embedded Win-GRAF SoftLogic (IEC 61131-3) |
| |
● |
Hard Real-Time Capability |
| |
● |
VGA Port Output |
| |
● |
Modbus RTU/TCP (Master, Slave) |
| |
● |
Support eLogger HMI |
| |
● |
Redundant Power Inputs |
| |
● |
Operating Temperature: -25 ~ +75 °C |
|
|
| |
 |
The Win-GRAF WinPAC-8000-CE7 Series (WP-8128-CE7/8428-CE7/8828-CE7) is the new generation Windows CE 7.0 based PAC (Programmable Automation Controller) of ICP DAS. Each WP-8000-CE7 is equipped with a Cortex-A8 (1.0 GHz) CPU running a Windows CE 7.0 operating system, a variant of input/output ports (VGA, USB, Ethernet, RS-232/485), and 1/4/8 expansion I/O slots that can be used to integrate high performance I-8K (parallel-type) and I-87K (serial-type) series I/O modules.
The benefits of running Windows CE 7.0 on a WinPAC device include hard real-time capability, achievable deterministic control and allowing PAC can have a PC-like window displays and operating environment. The WP-8xx8-CE7 series PACs are capable of running Win-GRAF (IEC 61131-3 Standard) software to develop logic control applications, and also supporting M.S. VS 2008 software (VB .NET, C#) to develop HMI and data management applications that can exchange data with Win-GRAF applications. So the application's design is more convenient and more practical. |
|
| |
 |
CE7 is a compact and hard real-time OS used to quickly create time critical and high performance applications. Using CE7 gives an ability to run PC-based control software such
as Visual Basic .NET, Virtual C#, SCADA software, SoftPLC, etc. |
 |
- FTP Server
- Web Server
- Telnet server
- Visual Studio.NET
|
|
| |
 |
Win-GRAF is a powerful, PLC-like, softlogic development software.It is installed on PC with windows 7 or 8 (or later version). It supports the international PLC language standard - IEC 61131-3 - Ladder Diagram (LD), Function Block Diagram (FBD), Sequential Function Chart (SFC), Structured Text (ST), Instruction Set (IL), suitable to develop applications for the full range of Win-GRAF PACs from ICP DAS. |
|
 IEC 61131-3 Standard Open PLC Syntax (LD, FBD, SFC, ST, IL) |
|
| Using ST Syntax in the FBD or LD Program |
| Event Triggered Data Binding (Exchange Data between PACs) |
| Online Debugging/Control/Monitoring, Offline Simulation |
| On Line Change |
| Various Protocols: |
- Modbus TCP/UDP, Modbus RTU/ASCII Master
- Modbus TCP, RTU Slave
- DCON ... |
| Plenty of Functions, Function Blocks, I/O Boards |
| Redundancy (For XP-8x38-CE6 PAC only) |
| |
|
| |
|
 |
Note: Except for specially noted items, all applications are applicable to the Win-GRAF PAC (i.e., WP-8xx8, WP-5xx8-CE7,
WP-8xx8-CE7, WP-9xx8-CE7, VP-x2x8-CE7, XP-8x38-CE6 PAC). |
 Schedule Control  |
Modbus Master Ports |
 |
|
| On Line Change |
|
| Replace the current running project to a new modified one
without stopping the project. |
|
 |
| eLogger HMI |
Modbus RTU/TCP Slave Ports |
|
 |
| Event Triggered Data Binding |
DCON Remote I/O |
| Exchange data between PACs. |
|
 |
 |
| Intelligent Win-GRAF 3G Solution |
|
Only the WG-Communication Server (behavior like a Cloud Server) needs a public IP (support Domain Name).
Other PACs and PCs that connect to this Server no need a public IP. |
|
| The user can monitor the remote PAC by using a 3G wireless network or an intranet. |
|
The user can use the Win-GRAF Workbench to connect to a remote PAC to debug/update the Win-GRAF program or
update the Win-GRAF PAC Driver. |
|
| The PAC can actively send a Log File to a PC (WG-Communication-Server). |
|
 |
| Support VS 2008 Development |
|
The Win-GRAF PACs support to use VS 2008 (VB.net, C#) to develop user own HMI and data management
programs, and can exchange variables with the Win-GRAF control programs. |
|
 |
| |
| Create Your Own Functions and Function Blocks |
For some reason (like business protection, integration with your own product protocol, and etc.), you can develop your
own functions and function blocks by VS 2008. Then, you can use these functions and function blocks in
the Win-GRAF project. |
|
 |
| PID Control |
| Can Control more than 200 PID in one PAC. |
|
 |
| |
| |
|
| |
|
 |
| Models |
WP-8128-CE7 |
WP-8428-CE7 |
WP-8828-CE7 |
| System Software |
| OS |
Windows CE 7.0 |
| .Net Compact Framework |
3.5 |
| Embedded Service |
FTP server, Web server (supports VB script, JAVA script), Embedded SQL server |
| Multilanguage Support |
English, German, French, Spanish, Russian, Italian, Korean, Simplified Chinese, Traditional Chinese |
| Development Software |
| Win-GRAF Software |
Win-GRAF |
IEC 61131-3 standard |
| Languages |
LD, ST, FBD, SFC, IL |
| Max. Code Size |
2 MB |
| Scan Time |
3 ~ 15 ms for normal program
15 ~ 50 ms for complex or large program |
| Non-Win-GRAF |
Options: VS.NET 2008 (VB.NET, C#.NET, C) |
| CPU Module |
| CPU |
Cortex-A8 (1.0 GHz) |
| DDR3 SDRAM |
512 MB |
| MRAM |
128 KB |
| Flash |
256 MB |
| EEPROM |
16 KB |
| Memory Expansion |
microSD socket with a 4 GB microSD card (support up to 32 GB) |
| RTC (Real Time Clock) |
Provides seconds, minutes, hours, day of week, month, year |
| 64-bit Hardware Serial Number |
Yes, for Software Copy Protection |
| Dual Watchdog Timers |
Yes |
| Programmable LED Indicator |
1 |
| Rotary Switch |
Yes (0 ~ 9) |
| DIP Switch |
- |
Yes (8 bits) |
Yes (8 bits) |
| VGA & Communication Ports |
| VGA |
800 x 600, 1024 x 768 |
| Ethernet |
RJ-45 x 2, 10/100/1000 Base-T (Auto-negotiating, Auto MDI/MDI-X, LED indicators) |
| USB 2.0 |
2 |
| COM0 |
Internal communication with the high profile I-87K series modules in slots |
| COM1 |
RS-232 (RxD, TxD and GND); Non-isolation |
| COM2 |
RS-485 (Data+, Data-) with internal self-tuner ASIC;
3000 VDC isolated |
| COM3 |
- |
Yes |
Yes |
RS-232/RS-485
(RxD, TxD, CTS, RTS and GND for RS-232;
Data+ and Data- for RS-485);
non-isolated |
| COM4 |
- |
Yes |
Yes |
| RS-232 (RxD, TxD, CTS, RTS, DSR, DTR, CD, RI and GND); non-isolated |
| I/O Expansion Slots |
| Slot Number |
1 |
4 |
8 |
| Note: For High Profile I-8K and I-87K Modules Only |
| Mechanical |
| Dimensions (W x L x H) |
95 mm x 132 mm x 111 mm
|
231 mm x 132 mm x 111 mm |
355 mm x 132 mm x 111 mm |
| Installation |
DIN-Rail or Wall Mounting |
| Environmental |
| Operating Temperature |
-25 ~
+75 °C |
| Storage Temperature |
-30 ~
+80 °C |
| Ambient Relative Humidity |
10 ~ 90 % RH (non-condensing ) |
| Power |
| Input Range |
+10 ~ +30 VDC |
| Isolation |
1 kV |
| Redundant Power Inputs |
Yes, with one power relay (1 A @ 24 VDC) for alarm |
| Capacity |
1.0A, 5V supply to CPU and backplane, 0.6A, 5V supply to I/O expansion slots, total 8 W |
1.1A, 5V supply to CPU and backplane, 4.9A, 5V supply to I/O expansion slots, total 30 W |
1.2A, 5V supply to CPU and backplane, 4.8A, 5V supply to I/O expansion slots, total 30 W |
| Power Consumption |
7.3 W (0.3 A @ 24 VDC) |
9.1 W (0.38 A @ 24 VDC) |
9.6 W (0.4 A @ 24 VDC) |
|
| |
|
 |
| Protocols (Note that certain protocols require optional devices) |
| NET ID |
1 ~ 255, for Modbus TCP/RTU Slave, user-assigned. |
| Modbus TCP Master |
A max. of 32 IP links to access/control the devices supporting Standard Modbus TCP Slave protocol. |
| Modbus RTU/ASCII Master |
A max. of 36 ports: COM1 ~ 37 (*) to connect other Modbus Slave devices(Like M-7000).
Recommend connecting no more than 32 devices in each port for better scan rate. |
| Modbus RTU Slave |
A max. of 16 ports: COM1 ~ 37 (*) for connecting SCADA/HMI/OPC Server. |
| Modbus TCP Slave |
Two Ethernet ports (LAN1 & LAN2) support up to 32 connections. If the PAC uses 1 connection to connect each PC/HMI, it can connect up to 32 PCs/HMIs; If the PAC uses 2 connections to connect each PC/HMI, it can connect up to 16 PCs/HMIs; If one of the Ethernet port malfunctions, the other one can still be used to connect the PC/HMI. |
| User-defined Protocol |
Custom protocols can be applied at COM1~ 37 (*) by using Serial communication functions or function blocks. |
| DCON Remote I/O |
A max. of 16 RS-485 ports: COM1 ~ 37 (*). Each port can connect max. 50 nos I-7000 series modules or
50 nos I-87xxxW I/O modules in expansion units (I-87K4, I-87K8, I-87K9, RU-87P8, RU-87P4).
Recommend connecting no more than 32 modules in each port for better scan rate. |
| Local I/O Modules |
Supports only high profile I/O modules. Slot 0~7 supports I-8xxxW parallel I/O modules and I-87xxxW serial I/O modules. (Refer Optional I/O List) |
| App Protection |
Using the unique 64-bit (8 bytes) PAC serial number to generate a protection password by your own algorithm to protect your Win-GRAF application. Then, if someone intend to copy your application in the PAC to another new PAC with the same PAC model, this application will not work properly in that new PAC.
|
| Data Binding |
Exchange data between ICP DAS Win-GRAF PAC via Ethernet ports (LAN1 and LAN2). The data transmission is event triggered. It is much efficient than polling way. Beside, user can setup the Redundant Binding in two ethernet ports by Software, then if one Ethernet port fail, it can switch to use the other port. |
| On Line Change |
For application field that not allowed to stop the Win-GRAF program and wish to run a new program modified a little from the original program. |
| Modbus RTU I/O |
When software enables Modbus RTU Master function, the PAC can connect ICP DAS M-7000 and tM series and LC series I/O modules which support Modbus RTU protocol. |
| Modbus TCP I/O |
When software enable Modbus TCP Master function, the PAC can connect ICP DAS I-8KE4/8-MTCP, PETL-7000, tPET/tET series I/O modules which support Modbus TCP protocol. |
| HART Master |
Support I-87H17W modules in slot 0 to 7 to communicate with other HART devices. |
| Schedule Control |
Supports the "Schedule-Control Utility" (free) to implement schedule control. Each PAC can control max. 10 Targets (devices) with different schedule settings in each day / holiday / special day / season / year. |
| Retain Variables |
Built-in the fast retain memory that can retain up to 12,000 Win-GRAF variables. |
| File Access and Data Log |
The Win-GRAF supports file operation functions to read/write files in the PAC's micro_SD or flash memory to do data log or file access. |
| eLogger HMI |
Support to run HMI program (developed by the eLogger) together with the Win-GRAF logic-control program in the same PAC. |
| Optional I/O List (Go to I-8K, I-87k Selection Guide) |
| Digital Input (DI) |
I-8040W, I-8040PW, I-8046W, I-8051W, I-8052W, I-8053W, I-8053PW, I-87040W, I-87040PW,
I-87046W, I-87051W, I-87052W, I-87053W, I-87053PW, I-87053W-A2, I-87053W-A5, I-87053W-E5 |
| Digital Input/Output (DIO) |
I-8042W, I-8050W, I-8054W, I-8055W, I-87042W, I-87054W, I-87055W |
| Digital Output (DO) |
I-8037W, I-8041W, I-8041AW, I-8056W, I-8057W, I-87037W, I-87041W, I-87057W, I-87057PW |
| Relay Output |
I-8060W, I-8063W, I-8064W, I-8068W, I-8069W, I-87061W, I-87061PW, I-87063W, I-87064W,
I-87065W, I-87066W, I-87068W, I-87068W-2A, I-87069W, I-87069PW |
| AC Input |
I-8058W, I-87053W-AC1, I-87058W, I-87059W |
| Analog Input (AI) |
I-8017DW, I-8017HW, I-8017HCW, I-87017W, I-87017RW, I-87017RCW, I-87017DW, I-87017W-A5,
I-87017ZW, I-87018W, I-87018RW, I-87018PW, I-87018ZW, I-87019PW, I-87019RW, I-87019ZW |
| Analog Output (AO) |
I-8024W, I-87024CW, I-87024UW, I-87024DW, I-87024RW, I-87024W, I-87028CW, I-87028UW,
I-87028VW, I-87028VW-20V |
| Multifunction (DIO, AIO) |
I-87026W |
Temperature
Input |
Thermistor |
I-87005W |
| RTD |
I-87013W, I-87015W, I-87015PW |
| T/C |
I-87018W, I-87018RW, I-87018PW, I-87018ZW, I-87019PW, I-87019RW, I-87019ZW |
| Strain Gauge |
I-87016W |
| Counter/Frequency Input |
I-8084W, I-87082W, I-87084W |
| Encoder Input |
I-8093W |
| PWM Output |
I-8088W |
| HART |
I-87H17W |
| GPS |
GPS-721 |
| Communication Module |
I-8112iW, I-8114W, I-8114iW, I-8142iW, I-8144iW |
| Temperature & Humidity Input |
DL-100T485, DL-100T485-W, DL-100T485P, DL-100T485P-W (DCON Protocol)
DL-100TM485, DL-100TM485-W, DL-100TM485P, DL-100TM485P-W (Modbus RTU Protocol) |
* Note: COM6 ~ COM37 ports are located in the expansion boards if they are installed in slot 0 ~ 7 of WP-8xx8-CE7.
* WP-8128-CE7 has no COM3 and COM4. |
|
| |
|
 |
| WP-8128-CE7 |
Win-GRAF based WinPAC-8000-CE7 with 1 I/O Slot |
| WP-8428-CE7 |
Win-GRAF based WinPAC-8000-CE7 with 4 I/O Slots |
| WP-8828-CE7 |
Win-GRAF based WinPAC-8000-CE7 with 8 I/O Slots |
|
| |
 |
| Win-GRAF Development Software |
| Win-GRAF Workbench |
Win-GRAF Workbench Software (Large I/O Tags) with one USB Dongle. |
|
| |
 |
| Power Supply |
24 VDC Power Supply with DIN-Rail Mounting (RoHS) |
| Ethernet Switch |
5 to 8 Ports Real-time Redundant Ring Ethernet Switch (RoHS) |
| 5 to 16 Ports Unmanaged Industrial Ethernet Switch (RoHS) |
| Converter |
RS-232/422/485 Converter (RoHS) |
| USB to RS-232/422/485 Converter (RoHS) |
| TPM-4100 / TP-4100 |
10.4" (800 x 600) resistive touch panel monitor with RS-232 or USB interface |
|
| |
|
|
| |
|
|
