PISO-CAN200E-D / PISO-CAN200E-T PCI Express CAN Communication Card
PISO-CAN200E-D ~NEW ~
PISO-CAN200E-T ~NEW ~
PISO-CAN200E can represents an economic solution of an active CAN board with express PCI bus. It has 2 independent CAN bus communication ports with 5-pin screw terminal connector or 9-pin D-sub connector, and has the ability to cover a wide range of CAN applications. Besides, PISO-CAN200E uses the new CAN controller Phillips SJA1000T and transceiver 82C250, which provide bus arbitration, error detection with auto correction and re-transmission function.
DeviceNet
is a low level network that provides connections between simple
industrial devices (sensors, actuators) and higher level devices
(controllers). It allows direct peer to peer data exchange between
nodes in an organized and, if necessary, deterministic manner.
We provides DeviceNet library for users to develop the specific
DeviceNet application by PISO-CAN200E. In addition, we also
provide the DeviceNet diagnosis application tool to monitor and
diagnose the DeviceNet message through CAN network. It provides
the DeviceNet communication protocol interface to control and
analysis the DeviceNet slaves. DevcieNet Application Tool Features
Auto detecting DeviceNet slave devices
IO monitor
Message monitor & diagnosis
Support UCMM capable devices
Support the Predefined Master/Slave connection
set
