C Language Based £gPAC-5000 (MiniOS7 Inside)

The £gPAC-5000 has a 16-bit CPU running a DOS like OS (called MiniOS7), communication ports of Ethernet, RS-232, RS-485 and one expansion bus to add one extra I/O board. Users can use C compilers to create 16-bit executable files (*.exe) to develop programs for £gPAC-5000. The recommend free compilers are Turbo C 2.0 or Turbo C++ 1.0.1. There are many demo programs for reference. Beside that, for TCP/IP programming, we provide a TCP/IP server template that named XServer. It is a very powerful, easy use and flexible tool that can save 90% developing time.
Model CPU Flash SRAM Memory Expansion Ethernet PoE GPS GPRS RS-232/485 Power Saving

£gPAC-5001(D)
£gPAC-5001P(D)		 80 MHz 512 KB 512 KB microSD 10/100 BaseTX - - - 1/1 -


£gPAC-5001-FD microSD + 256 MB Flash - - -

£gPAC-5002 768 KB microSD - - -


£gPAC-5002-FD microSD + 256 MB Flash - - -

£gPAC-5002-NV microSD + 1 MB NVRAM - - -


£gPAC-5002-SM microSD + 512 KB Battery Backup SRAM - - -


£gPAC-5101
£gPAC-5101P		 80 MHz 512 KB 512 KB microSD 10/100 BaseTX -
Yes		 Yes - 1/1 -

£gPAC-5101-FD
£gPAC-5101P-FD		 microSD + 256 MB Flash -
Yes		 Yes -

£gPAC-5102
£gPAC-5102P		 768 KB microSD -
Yes		 Yes -

£gPAC-5102-FD
£gPAC-5102P-FD		 microSD + 256 MB Flash -
Yes		 Yes -

£gPAC-5102-NV
£gPAC-5102P-NV		 microSD + 1 MB NVRAM -
Yes		 Yes -

£gPAC-5102-SM
£gPAC-5102P-SM		 microSD + 512 KB Battery Backup SRAM -
Yes		 Yes -


£gPAC-5201 80 MHz 512 KB 512 KB microSD 10/100 BaseTX - - Yes 1/1 -

£gPAC-5201-FD microSD + 256 MB Flash - - Yes

£gPAC-5202 768 KB microSD - - Yes

£gPAC-5202-FD microSD + 256 MB Flash - - Yes

£gPAC-5202-NV microSD + 1 MB NVRAM - - Yes

£gPAC-5202-SM microSD + 512 KB
Battery Backup SRAM		 - - Yes


£gPAC-5301 80 MHz 512 KB 512 KB microSD 10/100 BaseTX - Yes Yes 1/1 -

£gPAC-5301-FD microSD + 256 MB Flash - Yes Yes

£gPAC-5302 768 KB microSD - Yes Yes

£gPAC-5302-FD microSD + 256 MB Flash - Yes Yes

£gPAC-5302-NV microSD + 1 MB NVRAM - Yes Yes

£gPAC-5302-SM microSD + 512 KB
Battery Backup SRAM		 - Yes Yes


  back




Will be available
Available soon
Will be phased out



ISaGRAF Based £gPAC-5000

ISaGRAF based £gPAC-5000. The controller fully supports all five of the IEC61131-3 standard PLC languages:
1. Ladder diagram.
2. Function block diagram.
3. Sequential function chart.
4. Structured text.
5. Instruction List plus flow chart.
It supports DCON and Modbus protocol to link to remote I/O modules via the RS-232/485 or Ethernet.
Model CPU Flash SRAM Memory Expansion Ethernet PoE GPS GPRS RS-232/485 Power Saving

£gPAC-5007
£gPAC-5007P		 80 MHz 512 KB 768 KB 512 KB Battery Backup SRAM 10/100 BaseTX -
Yes		 - - 1/1 -

£gPAC-5107
£gPAC-5107P		 -
Yes		 Yes -

£gPAC-5207 - - Yes

£gPAC-5307 - Yes Yes


  back
