C Language Based ViewPAC (MiniOS7 Inside)

The ViewPAC, VP-211x and VH-211x series, has a 16-bit CPU, 128 x 64 resolution graphic display, silicon rubber keypad, communication ports of Ethernet, RS-232, RS-485 and 3 I/O expansion slot. It also equipped a DOS-like OS, MiniOS7. Users can use C compilers to create 16-bit executable files (*.exe) to develop a program then download it to the controller. The user can choose Turbo C 2.0 or Turbo C++ 1.0.1 to compile this application program and generate a execution file. This execution file can be download to VP-211X and VH-211x via RS-232 port or ethernet port. We recommend the user to use Turbo C++ 1.01.

There are many demo programs for reference. Beside that, for TCP/IP programming, we provide a TCP/IP server template that named XServer. It is very powerful, easy use and flexible tool that can save 90% developing time.

ISaGRAF Based ViewPAC (MiniOS7 Inside)

The controller fully supports all five of the IEC61131-3 standard PLC languages:
1. Ladder diagram,
2. Function block diagram,
3. Sequential function chart,
4. Structured text,
5. Instruction List plus flow chart.
It supports Modbus protocol and can link to distributed I/O modules with Modbus or DCON protocol via the RS-232/485 or Ethernet.

Standard ViewPAC (Windows CE .NET 5.0 Inside)

The controller supports following software development tools:
1. DLLs of I/O modules for eVC, VS.Net 2003/2005/2008
2. DLLs of Modbus/RTU and Modbus/TCP for eVC and VS.Net 2003/2005/2008
3. OPC server (Quicker)

Standard ViewPAC (Android 1.6 Inside)

The controller supports following software development tools:
1. SDK for Linux environment
2. SDK for Windows environment
