| 技術規範 |
| 標準規範 |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow Control
Energy Efficient Ethernet (EEE) as per 802.3az; this provides power savings during idle network activity |
| 處理類型 |
Store & forward, wire speed switching |
| MAC 位址 |
8K |
| 資料封包緩衝記憶體 |
512KByte |
| 巨型封包 |
9216 Byte |
| 流量控制 |
IEEE802.3x flow control, back pressure flow control |
| 介面 |
| RJ-45 連接埠 |
10/100/1000 BaseT(X), 10/100BaseT(X) auto negotiation speed, full/half duplex mode, and auto MDI/MDI-X connection |
| LED 指示燈 |
PWR1, PWR2, FAULT, Link, Act |
| 靜電隔離保護 |
1500 Vrms 1 minute |
| 指撥開關 |
Ports loss link alarm mask |
| 控制埠 |
Debugging, Monitoring, Setting |
| 電源輸入 |
| 電源範圍 |
Flexible input +24/+48 VDC Nominal. ( +12to +48 VDC) |
| 功耗 |
0.16A @ 48VDC Idle without loading; 0.2A @ 48VDC with full loading (0.12 W per ports)
0.31A @ 24VDC idle without loading; 0.39A @ 24VDC with full loading (0.12 W per ports) |
| 警報乾接點 |
One relay output with current carrying capacity of 1A @ 30 VDC |
| 電源保護 |
Power reverse polarity protection |
| 連接器端子 |
6-Pin Removable Terminal Block (Power & Relay) |
| 機構 |
| 外殼 |
Metal with an IP30 ingress protection rating |
| 尺寸 |
51 mm x 154 mm x 118 mm |
| 安裝方式 |
DIN-Rail or Wall Mounting (with optional kit) |
| 使用環境 |
| 工作溫度 |
-40 °C to + 75 °C (-40 °F to 167 °F) |
| 儲存溫度 |
-40 °C to + 85 °C (-40 °F to 185 °F) |
| 濕度 |
10 ~ 90% RH, non-condensing |
