PISO-1730U – Universal PCI, 32–channel Optically Isolated Digital Input and 32-channel Optically Isolated Digital Open-collector Output Board (Current Sinking, NPN type)
New Products
2013-09-16
Introduction
The PISO-1730U card is a new generation product with RoHS compliance.The PISO-1730U supports 3.3 V/5 V PCI Bus and provides 32-channel Optically Isolated Digital Input and 32-channel Optically Isolated Digital Open-collector output that are arranged into four isolated banks. Each input channel adopts a photo-coupler input. Each digital output channel offers a Darlington transistor. The power supply of the input port may use the external power or the power from the PC side by using a DC/DC converter. The power supply of the output port requires the external power source. The PISO-1730U eliminates ground-loop problems and provides isolation that protects host computer from damaging voltages.
The PISO-1730U software is fully compatible with the PISO-P32C32U series software. Therefore, the new PISO-1730U card is totally compatible with PISO-P32C32U series card and requires no software modification. The PISO-1730U supports various OS such as Linux, DOS, Windows 98, Windows 2000, Windows NT, 32-/64-bit Windows XP/2003/2008/Vista/7 and Windows 8. It also provides the DLL and Active X control, and various language sample programs in Turbo C++, Borland c++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW to help users to quickly and easily develop their applications.
Feature: |
||
|
 |
|
|
|
||
|
  |
|
|
|
||
|
 |
|
|
|
||
|
 |
|
|
|
||
|
 |
|
|
|
||
|
||
