型號 |
數位輸入 |
數位輸出 |
通道數 |
類型 |
Sink/Source |
通道數 |
Sink/Source |
| |
XV107 |
8 |
濕接點 |
Source |
8 |
Sink |
| |
XV107A |
Sink |
Source |
| |
XV110 |
16 |
乾接點/濕接點 |
Sink/Source |
- |
- |
| |
XV111 |
- |
- |
- |
16 |
Sink |
| |
XV111A |
Source |
|
| |
|
|
型號 |
數位輸入 |
繼電器輸出 |
通道數 |
類型 |
Sink/Source |
通道數 |
類型 |
| |
XV116 |
5 |
濕接點 |
Sink/Source |
2 |
信號繼電器 |
| 4 |
電源繼電器 |
 |
XV119 |
- |
9 |
信號繼電器 |
|
| |
|
|
型號 |
類比輸入 |
類比輸出 |
數位輸入 |
數位輸出 |
通道數 |
範圍 |
通道數 |
範圍 |
通道數 |
類型 |
Sink/Source |
通道數 |
Sink/Source |
 |
XV303 |
- |
- |
4 |
0 V ~ +5 V, ±5 V, |
4 |
濕接點 |
Sink/Source |
4 |
Relay, FormA, 6A |
| 0 V ~ +10 V, ±10 V, |
| 0 mA ~ +20 mA, |
| +4 mA ~ +20 mA |
|
XV305 |
4 |
±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1 V, ±2.5 V, ±20 mA, 0 ~ +20 mA, +4 ~ +20 mA
Thermocouple:
J, K, T, E, R, S, B, N, C |
- |
- |
|
XV306 |
4 |
±1 V, ±2.5 V, ±5 V, ±10 V, ±20 mA,
0 ~ 20 mA,
4 ~ 20 mA |
- |
- |
|
XV307 |
- |
- |
2 |
0 V ~ +5 V, ±5 V,
0 V ~ +10 V, ±10 V,
0 mA~ +20 mA,
+4 mA ~ +20 mA |
|
XV308 |
8 |
±1 V, ±2.5 V, ±5 V, ±10 V, ±20 mA,
0 ~ 20 mA,
4 ~ 20 mA |
- |
- |
DI+DO=8 |
乾接點/濕接點 |
Source |
DI+DO=8 |
Sink |
|
XV310 |
4 |
±1 V, ±2.5 V, ±5 V, ±10 V, ±20 mA,
0 ~ 20 mA,
4 ~ 20 mA |
2 |
0 V ~ +5 V, ±5 V,
0 V ~ +10 V, ±10 V,
0 mA~ +20 mA,
+4 mA ~ +20 mA |
4 |
Source |
4 |
Source |
|
| |
|
| Encoder/Frequency/Counter Input |
|
|
型號 |
通道數 |
Encoder |
Counter |
Frequency |
Resolution |
Maximum counting rate |
|
XV484 |
4/8 |
CW/CCW, Dir/Pulse |
Up or Up/Down |
Yes |
32bit |
200 kHz |
|
| |
|
|
Model |
PWM Output |
Load Voltage |
Maximum counting rate |
通道數 |
類型 |
Sink/Source |
|
XV488 |
Internal Power
External Power |
+5 VDC
+3.5 ~ +50 VDC |
500 kHz |
8 |
PWM |
Sink, Source
Sink |
|
| |
|
|
Model |
Type |
Load Voltage |
Speed |
|
XV511i |
RS-485 |
4 Channels (Data+, Data-) |
921.6 K |
|
| Note：XV511i Supports UA-2241M/WP-2241M-CE7/LP-2241M Only. |
| |
|
| |
|
|
