The ISaGRAF MiniOS7 ViewPAC Series (VP-2117) is the ISaGRAF PAC (Programmable Automation Controller) with graphic display and keypad. Each is equipped with an 80186 CPU (16-bit and 80 MHz) running a MiniOS7 operating system, a STN LCD, a rubber keypad, 3 or no I/O slots, and a variety of input/output ports (Ethernet, RS-232/485, etc.). Its operating system, MiniOS7, can boot up in a very short time (0.4 ~ 0.8 seconds). It has a built-in hardware diagnostic function, and supports the full range of functions required to access all high profile I-8K and I-87K series I/O modules, such as DI, DO, DI/DO, AI, AO, Counter/Frequency, motion control modules, etc. Users can also choose RS-485 Remote I/O modules (I-7000 series) or expansion units (RU-87Pn or I-87Kn) plugged with high profile I-87K serial I/O modules. Compared with traditional HMI + PLC solutions, ViewPAC reduces overall system cost, space and gives you all the best features of HMIs and PLCs.
MiniOS7 Embedded Operating System (DOS-like)
Embedded ISaGRAF Ver.3 SoftLogic
Support IEC 61131-3 Standard
Support Graphic and Keypad functions
Accepts max. 64 KB ISaGRAF code size
80186 CPU (16-bit & 80 MHz)
3 I/O Expansion Slots (support High Profile I/O Modules)
2 ~ 25 ms for normal program
10 ~ 125 ms (or more) for complex or large program
CPU Module
CPU
80186, 80 MHz
SRAM
768 KB
Flash
512 KB
Flash Disk
64 MB NAND Flash
Dual Battery Backup SRAM
512 KB; data valid up to 5 years (for retain variables)
EEPROM
16 KB
NVRAM
31 bytes (battery backup, data valid up to 5 years)
RTC (Real Time Clock)
Provides seconds, minutes, hours, date, day of week, month, year
64-bit Hardware Serial Number
Yes, for Software Copy Protection
Watchdog Timers
Yes (0.8 second)
Communication Ports
Ethernet
RJ-45 x 1, 10/100 Base-TX (Auto-negotiating, Auto MDI/MDI-X,
LED indicators)
COM 0
Internal communication with the I-87K High profile modules in slot 0 ~ 2
COM 1
RS-232 (RxD, TxD and GND) Program download port; Non-isolated
COM 2
RS-485 (Data+, Data-) with internal self-tuner ASIC; 2500 VDC isolated
COM 3
RS-232/RS-485 (RxD, TxD, CTS, RTS and GND for RS-232, Data+ and Data- for RS-485);
Non-isolated
MMI (Man Machine Interface)
LCD
STN, 128 x 64 Dot Matrix LCD
Display Mode
Text + Graphics
Text Font
English + Simplified Chinese/Traditional Chinese
Rubber Keypad
24 keys
Buzzer
Yes
LED Indicators
3 Dual-Color LEDs
(PWR, RUN, LAN1, L1,L2, L3; L1 ~ L3 for User Programmable)
I/O Expansion Slots
Slot Number
3
Note: For High Profile I-8K and I-87K Modules Only
Mechanical
Dimensions (W x L x H)
182 mm x 158 mm x 125 mm
Installation
Panel Mounting
Ingress Protection
Front panel: IP65
Environmental
Operating Temperature
-15 ~ +55°C
Storage Temperature
-30 ~ +80°C
Ambient Relative Humidity
10 ~ 90% RH (non-condensing)
Power
Input Range
+10 ~ +30 VDC
Isolation
1 kV
Capacity
15 W
Consumption
6 W
Protocols (Note that certain protocols require optional devices)
NET ID
1 ~ 255, user-assigned by software
Modbus RTU/ASCII Master
A max. of 2 ports: COM1 ~ COM3 and COM5. (*) (To connect to other Modbus Slave devices.)
A max. of Modbus_xxx Function Block amount for 2 ports: 128.
Modbus RTU Slave
A max. of 2 ports: COM1 and one of COM2 or COM3.
(For connecting ISaGRAF, PC/HMI/OPC Server and HMI panels.)
Modbus TCP/IP Slave
Ethernet port supports Modbus TCP/IP Slave Protocol for connecting ISaGRAF & PC/HMI up to 6 connections.
User-defined Protocol
Custom protocols can be applied at COM1~3 and COM5~16 using Serial communication function blocks. (*)
Remote I/O
One of COM2 or COM3 supports I-7000 I/O modules, I-87K base + I-87K Serial I/O boards, or RU-87Pn + I-87K High Profile I/O boards as remote I/O. A max. of 64 I-7000/87K remote I/O modules can connect to one PAC.
Fbus
Built-in COM3 Port to exchange data between ICP DAS’s ISaGRAF PACs.
Ebus
Used to exchange data between ICP DAS ISaGRAF Ethernet PACs via the Ethernet port.
Send Email
Provide functions to send email to a max. of 10 receivers with a single attached file via the Ethernet port through internet. The max. of file size is about 488 KB.
SMS:Short Message Service
One of COM3 or COM5 can link to a GSM
modem to support SMS. The user can request data/control the controller via a cellular phone. The controller can also
send data and alarms to the user’s cellular phone. (*) Optional GSM Modem: GTM-201-RS232 (850/900/1800/1900 GSM/GPRS External Modem)
CAN/CANopen
Amax. of 3 ports: COM1, 3 or COM5 ~ COM12 (*) can connect to one I-7530 (converter: RS-232 to CAN) to support CAN/CANopen devices and sensors. One PAC supports a max. of 3 RS-232 ports to connect a max. of 3 I-7530. (FAQ-086)
FRnet I/O
Enable a max. of 3 pcs. I-8172W boards to be used to connect to FRnet I/O modules, such as FR-2057, FR-32R. (Max. 768-ch. DI + 768-ch. DO)
All remote I-7000 & I-87K DI modules support counters.
Max. count/frequency: 16-bit (0~65535), 100 Hz.
High Speed Counter
Max. count/frequency for I-87082W: 32-bit, 100 kHz
Max. count/frequency for I-8084W: 32-bit, 250 kHz
Encoder
I-8093W: 3-axis Encoder Module, max. 1 MHz for quadrant input mode, max. 4 MHz for
Pulse/Direction and CW/CCW input mode. (FAQ-112)
I-8084W: 250 kHz max., 4-ch Encoder, can be Pulse/Direction or Up/Down, or A/B Phase
(Quad. mode); Not support Encoder Z-index. (FAQ-100)
ISaGRAF based ViewPAC with 3 I/O Slots (English + Simplified Chinese Font) (RoHS)
VP-2117-TC CR
ISaGRAF based ViewPAC with 3 I/O Slots (English + Traditional Chinese Font) (RoHS)
ISaGRAF Development Software
ISaGRAF-256
ISaGRAF Workbench Software Ver.3 (256 I/O Tags) with one USB Dongle
ISaGRAF-32
ISaGRAF Workbench Software Ver.3 (32 I/O Tags)
Note: No upgrade service from ISaGRAF-32 to ISaGRAF-256 is available.
(ISaGRAF-32 can be used to control more than 32 I/O tags. Please refer to Ch. 3.4 of the ISaGRAF User Manual.)
