USB-2068-18
10-channel Digital Input and 8-channel Digital Output Module

~ New ~
Model: USB-2068-18


The USB-2068-18 is an 8-channel Form C relay output and 10-channel digital input module with the USB interface. All digital input channels can be used as 32-bit counters. In addition, the digital input channels can be selected as sink/source type and dry/wet contact via wire connections. There are also options for configuring power-on and safe values. 8 kV ESD protection(for all channels) and 3750 VDC intra-module isolation(for digital input channels) are also provided to enhance noise protection capabilities in industrial environments.

Compare with traditional PC I/O card, it is waste of time to open chassis and configure I/O board. In ICP DAS USB I/O, you will enjoy the simply controlling I/O in the efficient way. ICP DAS USB I/O equips USB bus powered feature, one cable to access I/O and provide power without additional power wiring.

The USB I/O utility can help users to configure and control USB-2068-18 quickly and easily without programming; In addition, we also provide the friendly API library and demos for users to develop own USB application with various application development tools (VB/C++/C#.NET/VB.NET). Therefore, the USB-2068-18 is the perfect way to add control capability to any USB capable computer.

  • 10-channel digital input and 8-channel relay output.
  • Dry Contact and Wet Contact Selectable via Wire Connections
  • All Digital Input Channels can used as 32-bit Counters
  • Form C Relay Output
  • 8kV ESD protection
  • Wide Operating Temperature Range
  • 3000 VDC Intra-Module Isolation
  • USB 2.0 Full-Speed (12Mbps)
  • USB Bus Powered
  • Lockable USB cable
  • Driver Free

  • Automation
  • Measurement and testing
  • Laboratory research

USB-2K Utility
USB-2K Utility provides a simple way to easily test and instant acquire data for all ICP DAS USB IO series modules without programming.
  • USB module configuration
  • I/O configuration
  • Log Data analysis
  • Easy to test

VB/C++/C#.NET/VB.NET SDK
ICP DAS provides a SDK for USB I/O modules to help user to develop own project easily and quickly. The SDK can be supported in VB/C++/C#.NET/VB.NET to fulfill project development.

Relay Output
Channels 8
Output Type Form C
Contact Rating (Resistive Load) 0.25 A @ 250 VAC
0.24 A @ 220 VAC
2 A @ 30 VDC
Operate Time 3 ms (typical)
Release Time 4 ms (typical)
Insulation Resistance 109 Ω at 500VDC
Dielectric Strength Between Open Contact 1000 Vrms (1 min.)
Between Coil and Contacts 1500 Vrms (1 min.)
Endurance Mechanical 1 x 108 ops
Electrical 2 x 105 ops (at 30 V / 2 A)
Power On Value Yes
Safe Value Yes
Digital Input / Counter
Channels 10
TypeDry Contact Close to GND
Wet Contact Sink/Source
On Voltage Level +10 ~ 50 VDC
Off Voltage Level +4 VDC Max.
Counters Max. Count 4294967295 (32-bit)
Max. Input Frequency 500 Hz
Min. Pulse Width 1ms
Input Impedance 10 KΩ
Overvoltage Protection 70 VDC
Communication
Interface USB 2.0 Full-Speed (12Mbps)
Watchdog 1 Hardware watchdog (1.6 second)
1 Software watchdog (Programmable)
LED Indicators
System LED Indicators 3 LEDs as Power, Run and Error
I/O LED indicators Yes, 12 LEDs Digital Input/ Relay Output Indicator
Isolation
Intra-Module Isolation, Field-to-Logic 3000 VDC
EMS Protection
ESD (IEC 61000-4-2) 8 kV contact for each terminal
16 kV air for random point
Mechanical
Dimensions (W x L x H) 31 mm × 129 mm × 147mm
Environmental
Operating Temperature -25 ~ +75 °C
Storage Temperature -40 ~ +85 °C
Humidity 10 ~ 95% RH, non-condensing
Power
Power Consumption 2.3 W (Max.)

USB-2068-18 10-channel Digital Input, 8-channel Relay Output Module
