home > product> solutions > pac > WinPAC > WinPAC-8000 Selection Guide


Will be available
Available soon
Will be phased out
Phased out
Standard WinPAC(Windows CE .NET 5.0/7.0 Inside)
The controller supports following software development tools:
1. DLLs of I/O modules for eVC, VS.Net 2003/2005/2008
2. DLLs of Modbus/RTU and Modbus/TCP for eVC and VS.Net 2003/2005/2008
3. OPC server (Quicker)
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution USB RS-232/
485		 I/O Slot Memory Expansion Audio
WP-8121-CE7 CE 7.0 None Cortex-A8, 1.0 GHz 256 MB 512 MB
DDR3		 1024 x 768 2 2 1 microSD –
WP-8421-CE7 4 4
WP-8821-CE7 8

WP-8131 CE 5.0 None PXA270, 520 MHz 128 MB 128 MB 1024 x 768 2 2 1 microSD –
WP-8431 4 4
WP-8831 8

  WP-8141 CE 5.0 None PXA270
520 MHz		 96 MB 128 MB 800 x 600 1 2 1 microSD –
  WP-8441 4 4
  WP-8841 8
TOP | HOME

Will be available
Available soon
Will be phased out
Phased out
Win-GRAF Based WinPAC (Windows CE .NET 5.0/7.0 Inside)
The controller fully supports all five of the IEC61131-3 standard PLC languages:
1. Ladder diagram.
2. Function block diagram.
3. Sequential function chart.
4. Structured text.
5. Instruction List.
It supports Modbus protocol and can link to distributed I/O modules with Modbus or DCON protocol via the RS-232/485 or Ethernet.
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution USB RS-232/
485		 I/O Slot Memory Expansion Audio
WP-8128-CE7 CE 7.0 Win-GRAF Cortex-A8, 1GHz 256 MB 512 MB 1024 x 768 2 2 1 microSD –
WP-8428-CE7 4 4
WP-8828-CE7 8

WP-8148 CE 5.0 Win-GRAF PXA270, 520 MHz 96 MB 128 MB 800 x 600 1 2 1 microSD –
WP-8448 4 4
WP-8848 8

TOP | HOME

Will be available
Available soon
Will be phased out
Phased out
ISaGRAF Based WinPAC(Windows CE .NET 5.0 Inside)
The controller fully supports all five of the IEC61131-3 standard PLC languages:
1. Ladder diagram.
2. Function block diagram.
3. Sequential function chart.
4. Structured text.
5. Instruction List plus flow chart.
It supports Modbus protocol and can link to distributed I/O modules with Modbus or DCON protocol via the RS-232/485 or Ethernet.
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution USB RS-232/
485		 I/O Slot Memory Expansion Audio
WP-8137 CE 5.0 ISaGRAF PXA270, 520 MHz 128 MB 128 MB 1024 x 768 2 2 1 microSD –
WP-8437 4 4
WP-8837 8

  WP-8147 CE 5.0 ISaGRAF PXA270, 520 MHz 96 MB 128 MB 800 x 600 1 2 1 microSD –
  WP-8447 4 4
  WP-8847 8

TOP | HOME

Will be available
Available soon
Will be phased out
Phased out
InduSoft Based WinPAC(Windows CE .NET 5.0 Inside)
The controller can be used to develop following applications:
1. Human Machine Interfaces (HMI)
2. Supervisory Control and Data Acquisition System (SCADA)
3. Web server
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution USB RS-232/
485		 I/O Slot Memory Expansion Audio
WP-8129-CE7 CE 7.0 InduSoft Cortex-A8, 1.0 GHz 256 MB 512 MB
DDR3		 1024 x 768 2 2 1 microSD –
WP-8429-CE7 4 4
WP-8829-CE7 8

WP-8139 CE 5.0 InduSoft PXA270, 520 MHz 128 MB 128 MB 1024 x 768 2 2 1 microSD –
WP-8439 4 4
WP-8839 8

WP-8149 CE 5.0 InduSoft PXA270, 520 MHz 96 MB 128 MB 800 x 600 1 2 1 microSD –
WP-8449 4 4
WP-8849 8

TOP | HOME

Will be available
Available soon
Will be phased out
Phased out
ISaGRAF & InduSoft Based WinPAC(Windows CE .NET 5.0 Inside)
The controller includes features of ISaGRAF and InduSoft.
Model OS Pre-Installed Software CPU Flash SDRAM VGA Resolution USB RS-232/
485		 I/O Slot Memory Expansion Audio
WP-8136 CE 5.0 ISaGRAF & InduSoft PXA270, 520 MHz 128 MB 128 MB 1024 x 768 2 2 1 microSD –
WP-8436 4 4
WP-8836 8

WP-8146 CE 5.0 ISaGRAF & InduSoft PXA270, 520 MHz 96 MB 128 MB 800 x 600 1 2 1 microSD –
WP-8446 4 4
WP-8846 8

TOP | HOME
