- New Product Release: tM-7565
Tiny USB to CAN Converter
Jan. 31, 2019 - Introduction:ICP DAS provides a wide variety of USB to CAN product solutions that are highly recommended in the marketplace. These USB to CAN converters assist users to implement the communication between USB and CAN based networks. To meet the low cost requirement from our customers, ICPDAS provides a new USB to CAN converter solution – the tM-7565. The tM-7565 module is a tiny USB to CAN converter module that is suitable for narrow environments due to its small size. In addition, it is easy to use for CAN bus testing via a laptop as it has a USB interface. The tM-7565 module includes isolation on both power side and CAN bus side, and provides a faster performance than other USB to CAN modules. The tM-7565 functionality is fully compatible with the I-7565 module, and it also provides new functions such as listen only, which can be used to listen to CAN bus message and for error detection. Based on these features, the tM-7565 module is acost-effective and a practical solution for USB to CAN conversion.
- Applications:
-
- Utility:The VxCAN Utility is a configuration, diagnostic and test software tool that is designed to unleash the power of all CAN products from ICP DAS. It is based on the Virtual CAN technique, which creates the virtual CAN ports to match the physical CAN interfaces of the installed products (Refer to the ICP DAS web site for more details related to the Virtual CAN technique VxCAN Driver).
Consequently, it is no longer necessary to use various utilities or software interface to connecting to different CAN products. Users just need to focus on the project development and network diagnosis without concerning about what CAN product the system uses.
In order to satisfy requirements of various applications, the VxCAN Utility provides not only the functions of sending and receiving CAN messages, but also the functions for message trigger, group transmission and data record. Using these functions can help users to know what happen in the system network clearly, so that the system problems would be fixed more efficiently and simply. -
- Features:
- Internal Watchdog
- Fully compatible with the ISO 11898-2 standard, and CAN specifications 2.0A and 2.0B
- Supports a range of CAN Baud Rate from 10 K-bps to 1 M-bps, as well as user-defined CAN Baud Rate.
- Supports a range of USB Baud Rates from 110 bps to 230400 bps
- Build-in 120 Ω terminator resistor selectable via jumper
- Supports pair-connection mode
- Software buffer on both the CAN bus side and the USB side
- Supports user-defined end of characters in pair-connection mode
- Configurable communication mode(normal , pair-connection , and listen-only mode )
- Configurable CAN bus and USB parameters
- CAN Message logger functions
- Supports group sending of CAN messages.
- Able to monitor CAN Bus loading by the trend via a utility
- Supports configuration of trigger event for starting transmission, stopping reception or recording messages.
-
Comparison Table for USB to CAN Converter modules:
Models tM-7565 I-7565 I-7565-H1 I-7565-H2 Hardware CAN Interface Transceiver NXP TJA 1042 82C250 NXP TJA 1042 Max. CAN Baud Rate 1M bps Terminator Resistor 120Ω terminator resistor selectable via jumper Specification ISO 11898-2 Isolation DC-DC: 3000 VDC
Photocoupler: 2500 VrmsUSB Interface USB Interface Type B Max. USB Baud Rate 230400 bps 115200 bps 12 Mbps Mechanism Dimensions (W x H x D) 52 x 93 x 27 mm 72 x 118 x 33 mm Power Power Consumption 1W 1.5W Software Function Transparent O O O CAN Bus Listen Only Mode O X X Performance Performance CAN to USB: FPS >=520
USB to CAN: FPS >=520
(2.0A@1Mbps, 115200, n, 8, 1)CAN to USB: FPS >=338
USB to CAN: FPS >=382
(2.0A@1Mbps, 115200, n, 8, 1)FPS: 3000
