Release the Soft-GRAF Studio Version 1.05 : Add the Alarm List Function

ICP DAS release the new version 1.05 of Soft-GRAF Studio HMI (Human Machine Interface) software. The new version provides Alarm Lists function and supports the PAC WP-5147. In addition, with the Real-Time Trend Curve and Historical Trend Curve (max. recording 1 year) features supported since version 1.04, the Soft-GRAF Studio is more and more powerful and complete!

The Soft-GRAF Studio received many customers attention and praise since its first launch. Welcome to download and install it in the PC/Windows for creating a colorful HMI interface in the ISaGRAF WinCE PAC of ICP DAS. The supported PAC is now included XP-8xx7-CE6 , WP-8xx7, VP-25W7 / 23W7, WP-5147 series. User can edit the HMI screen by the graphical drag and drop operation. ICP DAS will continue to develop more new HMI features and provide the best technology and service to customers!

New features of the Soft-GRAF Studio

The following new features are very suitable for HMI of the industrial, mechanical ... and other control systems in the industrial and commercial applications.

1. Main Features of Alarm Lists Since V. 1.05 :

Support to record, display and search the alarm lists up to 1 year
Allow to export the Alarm data to an USB disk with one of the file formats "csv for excel" or "txt , Unicode"
Pop up an Alert message box to alert the operator when an alarm triggered
For VP-25W7 and VP-23W7, provide additional Beep Beep alarm sound
Support various user-defined Alarm Events and Messages
Support multi-language (Traditional Chinese, Simplified Chinese, English, moreK )

2. Features of Trend Curve and Angular Gauge since V. 1.04 :

Trend Curve: for creating a real-time trend to display maximum 3 curves and may also to enable the historical trend function to record them. Maximum 100 g_Trend objects are available for XP-8xx7-CE6 PAC, while, maximum 30 g_Trend objects are available for WP-8xx7, WP-5xx7, VP-25W7 / 23W7 PACs. The trend curves can present tracks of data changing by the time past. If enable the historical trend, the maximum time period to record is one year.

Angular Gauge: for displaying a Long, Short Integer or a Real value as an angular gauge in the HMI screen. The pointer of angular gauge can real-time show the value that displayed in max. 3 different colors for max. 3 sections. The value can also be scaled to fit the engineering format.

3. New demo program: Demo07 for Alarm List

Besides of the demo programs Demo01 ~ Demo06, ICP DAS provides demo program Demo07 for the version 1.05. Through the new demo example (Demo07) and the new version Soft-GRAF user manual (FAQ146), user can learn how to create the Alarm List in a short time.
