Release the Soft-GRAF Studio Version 1.03

Soft-GRAF Studio is an HMI (Human Machine Interface) software by ICP DAS. It is free to install in the PC/Windows for creating a colorful HMI interface in the ISaGRAF PAC of ICP DAS. User can edit the HMI screen by the graphical drag and drop operation. The Soft-GRAF Studio received many customers attention and praise. ICP DAS will continue to develop new features and provide the best technology and service to customers!

New functions since the Soft-GRAF Studio Version 1.03
The new functions since the Soft-GRAF Studio V.1.03:

1. Support multi-object selection and operation:
This new function supports to select multiple HMI objects and then do the multi-object clipboard operations, such as move, copy and delete. The multi-object function much increases the speed for the HMI design.

2. Provide new tool icons about the object layer:
Add two icons to adjust the object layer. The icons can move the objects to front/back or to forward/backward one layer. Using this functions can quickly change the objects layer and hide/display the HMI objects.

3. Provide more HMI pictures
Add more pictures or buttons in the Soft-GRAF Studio for more fields of application design. The HMI screen will be more beautiful and professional.

Related Web Links

Soft-GRAF Studio Website:
Software Website/Online Tutorial/My Sweet Home Video
ICP DAS home > product > solutions > software > SCADA/HMI > Soft-GRAF
http://www.icpdas.com/products/Software/Soft-GRAF/soft-graf.htm

Soft-GRAF Studio User Manual (FAQ-146)
ICP DAS home > support > FAQ > Software > FAQ-146
http://www.icpdas.com/faq/isagraf.htm

More ICP DAS ISaGRAF Products Information
ISaGRAF PAC Datasheet : http://www.icpdas.com/products/PAC/i-8000/data sheet/data sheet.htm
ISaGRAF PAC Web : http://www.icpdas.com/products/PAC/i-8000/isagraf.htm
ISaGRAF PAC Manual : http://www.icpdas.com/products/PAC/i-8000/getting_started_manual.htm
ISaGRAF PAC FAQ : http://www.icpdas.com/faq/isagraf.htm
I-8K & I-87K high profile I/O modules : http://www.icpdas.com/products/PAC/i-8000/8000_IO_modules.htm
