MSM-6226 , 24 Fast Ethernet + 2 Gigabit L2 Managed Switch, implemented 24 10/100Mbps TP + 2 Gigabit dual media ports with TP/SFP(or GBIC), is a standard switch that meets all IEEE 802.3/u/x/z Gigabit, Fast Ethernet and Ethernet specifications. The switch can be managed through RS-232 serial port via direct connection, or through Ethernet port using Telnet or Web-based management unit, associated with SNMP agent. With the SNMP agent, the network administrator can log on the switch to monitor, configure and control each port activity in a friendly way. The overall network management is enhanced and the network efficiency is also improved to accommodate high bandwidth applications.

In addition, the switch features comprehensive and useful function such as DHCP Option 82, QoS (Quality of Service), Spanning Tree, VLAN, Port Trunking, Bandwidth Control, Port Security, SNMP/RMON and IGMPv3 Snooping. It is suitable for both Metro-LAN and office application. The switch also intensifies the support of Power saving for reducing the power consumption by Power Management technique. It could efficient saving the switch power by auto detection of idle status of the client devices and providing different power according to the cable length of each port.

For more information, please visit the following web site:
Industrial Ethernet Switch & Fiber Switch
MSM-6226
