In order to save the installation space, the GW-7472 (IPGW-710) is offered in an amazing tiny form-factor that makes it easy to install in anywhere, even directly attached to a serial device or embedded into a machine. The GW-7472 (IPGW-710) features a powerful 32-bit MCU to handle efficient network traffic and it provides the IEEE 802.3af-compliant (classification, Class 1) Power over Ethernet (PoE) with a standard category 5 Ethernet cable. Through the NS-205PSE, PoE switch, the GW-7472 (IPGW-710) can be powered via the Ethernet cable. When there is no PoE switch on site, the GW-7472 (IPGW-710) provides another way to be powered from DC adapters. These two power interfaces are redundant. If one fails, another will take it over to supply the proper power to the GW-7472 (IPGW-710). |
