智慧型 RS-485 I/O 擴充單元

此單元是用來擴充 RS-485 網路上面的 I-87K 系列的 I/O 模組。 它具備一個電源模組、一個 RS-485 的通訊介面、一個 CPU 模組和數個 I/O 插槽。 只有高卡版本之 I-87K 系列的 I/O 模組可以插在這個單元上面。

最重要的特色是

1. 自動組態 (Auto configuration)
    每一個插槽的組態可以被預先設定、儲存在 CPU 模組上。當某一個模組被插入時,這個 CPU 模組就會把預先設定好的組態寫入這個
    模組。

2. 熱插拔 (Hot Swap)
    全部的 I-87K 模組的電路設計,都具有可熱插拔的功能。更換 I/O 模組時,這個 I/O 單元並不需要將電源關掉。

有了上面這兩項特色,維修將變成非常容易。假如有一個模組損壤了,工作人員只需要找一個新的模組將損壞的那一個換掉即可。整個系統不需要為了維修而停機,而且 I/O 模組的組態也會自動被 CPU 模組完成。

型號
自動組態
(Auto COnfiguration)
熱插拔
(Hot Swap)
最快 baudrate
電源推力
I/O 擴充槽

  RU-87P1
Yes
Yes
115.2 Kbps
5 W
1

  RU-87P2
8 W
2

  RU-87P4
30 W
4

  RU-87P8
30 W
8


Will be available
Available soon
Will be phased out
Phased out

RS-485 I/O 擴充單元

此單元只具備一個電源模組、一個 RS-485 的通訊介面和數個 I/O 插槽。它是用來擴充 RS-485 網路上面的 I/O 點數。只有 I-87K 和 m-87K 系列的 I/O 模組可以插在這個單元上面。
型號
最快 baudrate
電源推力
I/O 擴充槽

  I-87K4
115.2 Kbps
20 W
4

  I-87K5
5

  I-87K8
8

  I-87K9
9







智慧型 USB I/O 擴充單元

此單元是用RS-485 網路來擴充上面的 I-87K 系列的 I/O 模組。它具備一個電源模組、一個 USB 的通訊介面、一個 CPU 模組和數個 I/O 插槽。

最重要的特色是

1. 熱插拔 (Hot Swap)
    更換或插入 I-87K 模組時,USB-87Pn 並不需要關閉電源。因此整個系統可以持續運作,而無任何中斷。

2. 自動組態 (Auto configuration)
    I-87K 模組的組態可以被預先設定好,並儲存於 USB-87Pn 上的記憶体。當USB-87Pn 的電源啟動時,或是某一個 I-87K 模組插入時
    ,這個 USB-87Pn 就會自動檢查、回存組態設定到每個需要更新組態的 I-87K 模組上。

只有高版的 I-87K 模組可以插在這個單元上面。

型號 自動組態
(Auto Configuration)
熱插拔 (Hot Swap) 固定 baud rate 電源推力 I/O 擴充槽

Yes
Yes
115.2 Kbps
10 W
1

15 W
2

30 W
4

30 W
8





Will be available
Available soon
Will be phased out
Phased out

智慧型乙太網 I/O 擴充單元

此單元是用來擴充乙太網路上面的 I-87K 系列的 I/O 模組。它具備一個電源模組、兩個乙太網口、一個 CPU 模組和數個 I/O 插槽。 只有高卡版本之 I-87K 系列的 I/O 模組可以插在這個單元上面。

最重要的特色是
  1. 自動組態 (Auto configuration)
    每一個插槽的組態可以被預先設定、儲存在 CPU 模組上。當某一個模組被插入時,這個 CPU 模組就會把預先設定好的組態寫入這個模組。
  2. 熱插拔 (Hot Swap)
    全部的 I-87K 模組的電路設計,都具有可熱插拔的功能。更換 I/O 模組時,這個 I/O 單元並不需要將電源關掉。

有了上面這兩項特色,維修將變成非常容易。假如有一個模組損壤了,工作人員只需要找一個新的模組將損壞的那一個換掉即可。整個系統不需要為了維修而停機,而且 I/O 模組的組態也會自動被 CPU 模組完成。

型號 自動組態 熱插拔 乙太網 電源推力 I/O 擴充槽
  ET-87P4
Yes Yes 10/100 BaseTx 30 W
4
  ET-87P8
8






Will be available
Available soon
Will be phased out
Phased out

Intelligent Remote Redundant Ethernet I/O expansion unit

The unit is the intelligent remote redundant I/O unit with Modbus TCP protocol. It can be equipped with 2 power modules, 2 communication module, 8 I/O modules. The unit offers redundancy options for various functions- ranging from power redundancy to I/O redundancy. Besides, there are most of I/O modules, such as DI, DO, AI, AO, PI, PO, HART and etc, can be used in the units. Only the F-8K modules can be plugged in the unit.

The most important features are
  1. Auto configuration
    Each slot configuration can be pre-configured and stored in the CPU module, Once a module is plug in, the CPU module will write the pre-configured data to the module.
  2. Hot Swap
    All F-8K modules circuit design allow it to be hot swapped. The unit don't need to power off while swapping I/O modules.
  3. Redundancy
    Support redundant communication, power and I/O function to enhance the reliability of the system.
  4. Open Communication protocol
    Due to the Modbus TCP protocol, iDCS-8830 can be integrated in various PC/PAC/PLC system easily.
Model
Redundancy Auto Configuration Hot Swap
Ethernet
Power Supply
I/O slot
Yes Yes Yes 10/100 BaseTx 40 W
8
