New products

New product: SG-3383 1-channel Current Input to 3-channel Current Output Module

The SG-3383 is a 1-channel current input to 3-channel current output signal conditioning module that provides 3000 VDC 3-way isolation for input, output and power, together with 8 kV ESD Protection. The SG-3383 includes an LED that can be used to indicate whether the module is functioning correctly, and also includes VRs (Zero, Span) that can be used to calibrate the output range accuracy. The input bandwidth of the SG-3383 is typically 2.5 kHz. The SG-3383 can be easily mounted on a standard DIN Rail and can operate in environments where there is a wide temperature range.......more

New release

New Win-GRAF Application: Intelligent Win-GRAF 3G Solution

Some applications require the HMI / SCADA system in the control center to communicate with remote PACs (Programmable Automation Controller) via the Internet to monitor or collect data (e.g., temperature, humidity, voltage, current, etc.) in the application field for further analysis. And then convert them into useful information or a file. In the past, we usually delivered these application data via wired network where each PAC required a public IP on the Internet. However it’s getting more difficult to get a public IP nowadays. You need to pay much more money for it if each PAC requires a public IP. In addition, some application field are distributed in the remote districts where are hard-to-reach or unattended. The cost of wiring for such a long-distance communication is too expensive. For some harsh environments that unable to set up the remote wiring, the engineer must take a long-distance driving in order to get data or do some software maintenance. This spends too much time and it is so inconvenient and so inefficient......more

New Catalog and Short Form "High-quality, Industrial Data Acquisition and Control I/O Products for PC-based Systems"

The "High-quality, Industrial Data Acquisition and Control I/O Products for PCI-based Systems" Catalog and Short Form includes more than 170 high-quality industrial data acquisition and control products that can satisfy virtually any requirement. The ICP DAS range not only includes boards that support both the ISA and the PCI bus, but now also offers products that are compatible with the PCI Express (PCIe) standard. For each bus, a wide choice of Digital and/or Analog Input/Output boards is available. The total solution product lines add unlimited expansion capabilities to your communication and control systems. The new catalog provides full and detail information of these products for users to find a suitable solution and to expand system functions easily and quickly......more

New Catalog "Industrial Communication & Networking Products Catalog"

The "Industrial Communication & Networking Products" catalog (ICNP) includes all ICP DAS industrial communication products, such as bus converters, protocol converters, local communication and networking solutions. The total solution product lines add unlimited expansion capabilities to your communication and control systems. The new catalog provides full and detailed information of these products for users to find a suitable solution and to expand system functions easily and quickly.......more

Applications

Application for Generator Management System in Taipei 101 Building
The generator management system provides full range of control and management of the generators; the SCADA system with user-friendly interface is designed for easy operations. The system architecture adopted coherent communication, therefore when new features is added in the future, as long as the module or hardware uses the same communication, the new features can be seamlessly added without affecting the existing architecture. The distributed modules can function independently to acquire hardware status information, and can be replaced without shutting down the system. (more...)

PMC-5151 used in Power & Air Conditioning Monitoring System Application in Campus
For the resources of the earth are getting depleted faster in recent years, industries in all fields all set off a wave of energy saving and carbon reduction in order to avoid rising energy costs and save money. Under the trend of energy saving and carbon reduction, power monitoring gradually becomes an important project. In this application; PMMS (Power Monitor & Management Solution) from ICP DAS is used to monitor power & air conditioning in a campus. By using PMMS, the administrators in school can perceive the power consumption information of each building, classroom and electrical device in real time, and is able to analyze, assess or manage the usage of electricity, and then establish appropriate policy to achieve effective electricity usage, reduce the electricity bill and avoid penalties for exceeding contract capacity. (more...)

WISE Applications: Unmanned Facility Room Monitoring System & Hydraulic Control System
As the advance in science and technology development, the power system and the network system have become essential parts of modern life. No matter in the buildings, factories, or even outdoors, there are always control rooms with devices installed for power and network management and control. Due to the control rooms are always filled with all kinds of expensive devices and usually under high loading operations; the safety of access control, the monitoring of temperature and humidity, and power consumption management become important issues for the whole system. (more...)

UniDAQ - Development Software of ICP DAS PC-based I/O boards
In order to meet all kinds of requirements from different applications, ICP DAS has developed more than 132 industrial control I/O boards. UniDAQ is a software tool specially designed by ICP DAS to help users easily implement applications for these I/O boards. UniDAQ supports most frequently used ICP DAS PCI Bus and PCI Express boards and the sample code in various languages such as Visual C++ 6.0, Visual Basic 6.0, Delphi, Visual Basic.NET, Visual C#.NET, LabVIEW and MATLAB are also available for users to quickly implement control applications of the I/O boards. (more...)
