iKAN Industrial Modbus LED Display

Modbus LED Display
Model		Display	Communication Interfaces			Mechanical
Model		Message Pool	Ethernet		COM Ports	Dimensions (mm) (W × H × D)	Weight	Housing Material	Installation
	iKAN-116	128 common messages and 20 instant messages Up to 20 Unicode characters or 50 ASCII characters each	1 × RJ-45, 10/100 Base-TX	Modbus TCP Slave Max. 8 connections	RS-485 (Modbus RTU Slave)	1346 × 160 × 49	4 Kg	Aluminum	Wall mounting
	iKAN-116S					834 × 115 × 37.5	2 Kg
	iKAN-124					1986 × 160 × 49	4.6 Kg
	iKAN-124S					1218 × 115 × 37.5	2.5 Kg
	iKAN-208	128 common messages (Allows you to set Priority) Up to 20 Unicode characters or 50 ASCII characters each	2 × RJ-45, 10/100 Base-TX		RS-485 × 2	707 x 320 x 50	4 Kg
	iKAN-216					1346 × 320 × 49	8 Kg
	iKAN-224					1986 × 320 × 49	12 Kg

PROFIBUS LED Display
Model		Display	Communication Interfaces				Mechanical
Model		Message Pool	Ethernet		COM Ports	PROFIBUS	Dimensions (mm) (W × H × D)	Weight	Housing Material	Installation
	iKAN-116-PFB	128 common messages (Allows you to set Priority) Up to 20 Unicode characters or 50 ASCII characters each	2 × RJ-45, 10/100 Base-TX	Modbus TCP Slave Max. 8 connections	RS-485 x 1: PROFIBUS x 1	Baudrate: 9.6 k, 19.2 k, 45.45 k, 93.75 k, 187.5 k, 500 k, 1.5 M, 3 M, 6 M, 12 M; Protocol: DP-V0	1346 × 160 × 49	4 Kg	Aluminum	Wall mounting
	iKAN-116S-PFB						834 × 115 × 37.5	2 Kg
	iKAN-124-PFB						1986 × 160 × 49	4.6 Kg
	iKAN-124S-PFB						1218 × 115 × 37.5	2.5 Kg
	iKAN-208-PFB						707 x 320 x 50	4 Kg
	iKAN-216-PFB						1346 × 320 × 49	8 Kg
	iKAN-224-PFB						1986 × 320 × 49	12 Kg

CANopen LED Display
Model		Display	Communication Interfaces				Mechanical
Model		Message Pool	Ethernet		COM Ports	CANopen	Dimensions (mm) (W × H × D)	Weight	Housing Material	Installation
	iKAN-116-CPS	128 common messages (Allows you to set Priority) Up to 20 Unicode characters or 50 ASCII characters each	1 x RJ-45, 10/100 Base-TX	Modbus TCP Slave Max. 8 connections	RS-485 x 1; CAN x 1	Baudrate: 10 k, 20 k, 50 k, 125 k, 250 k, 500 k, 800 k, 1 Mbps; Protocol: CANopen DS-301 ver4.02, DS-401 ver2.1	1346 × 160 × 49	4 Kg	Aluminum	Wall mounting
	iKAN-116S-CPS						834 × 115 × 37.5	2 Kg
	iKAN-124-CPS						1986 × 160 × 49	4.6 Kg
	iKAN-124S-CPS						1218 × 115 × 37.5	2.5 Kg
	iKAN-208-CPS		2 x RJ-45, 10/100 Base-TX				707 x 320 x 50	4 Kg
	iKAN-216-CPS						1346 × 320 × 49	8 Kg
	iKAN-224-CPS						1986 × 320 × 49	12 Kg
