| Analog Input |
| Input Channel |
1 |
| Input Type |
0 ~ 2.5 V |
| Resolution |
12-bit |
| Sampling rate |
900Hz Max |
| Input Impedance |
100K Ohm |
| Over voltage Protection |
+/-5VDC |
| Isolation Voltage |
Non-isolation |
| Other specifications |
| Dimensions |
64 mm x 32 mm |
| Power requirement |
+5VDC |
| Environment |
| Environment with
I-7188XC or £gpac-7186 series Casing |
Operating Temperature :-25 ~ +75 ¢J |
| Storage Temperature : -40 ~ +80 ¢J |
| Relative Humidity : 5% to 90% Non-condensing |
|
|
