DP-660
24V/2.5A , 5V/0.5A Dual output Power supply |
|
| |
| |
 |
| Model: DP-660 |
|
|
|
| |
 |
DP-660 is a 65 watts,universal input switching mode power supply.
It is with 24V/5V output options. DP-660 is intended for power device like motor or solenoid application.Build in +5V 3T-regulator for DP-660 is for if there is a logical control circuit. |
| |
 |
- Input voltage: 85 VAC ~ 270 VAC
- Input frequency: 47 Hz ~ 63 Hz
- Inrush current (Cold start):
less than 30A at 115 VAC
less than 60A at 230 VAC
- DC Outputs:
+24 V/2.5 A
+5 V/0.5 A
- Efficiency: higher than 70% at rated load and 115 VAC
- Holdup time: 16ms at rated load and 115 VAC
- Over voltage protection: hiccup mode
- Short circuit protection: latch off
- Over voltage protection: latch off
- Operating temperature: 0 ~ 50 °C
- Cooling: free air convection
- Storage temperature: -40 °C ~ +85 °C
|
| |
 |
