ICP DAS ISaGRAF PAC release new drivers to support isolated Input/output modules I-87016W and I-87042W, and support Soft-GRAF HMI software to create colorful HMI pages. Furthermore, the XP-8xx7-CE6 series support motion modules, I-8094F / I-8094 / I-8092F, to achieve the motor motion control.
Please download the new version ISaGRAF drivers at :
http://oldweb.icpdas.com/products/PAC/i-8000/isagraf-link.htm
Support I-87016W and I-87042W V isolated I/O modules
New drivers support the I-87016W (2-channel Isolated Strain Gauge Input Module) and I-87042W (16-channel Isolated Digital Input & 16-channel Isolated Digital Output Module) I/O modules. These modules with isolated function can protect the controllers and devices from the noise signals for safety and long-term usage.
Detail I/O module information:
http://oldweb.icpdas.com/products/PAC/i-8000/8000_IO_modules.htm.
Support Soft-GRAF HMI V create a colorful HMI
The ISaGRAF PAC XP-8xx7-CE6, WP-8xx7 and VP-2xW7 series support Soft-GRAF HMI. With one ISaGRAF development software only, user can design both colorful HMI and automation control logic at the same time.
Soft-GRAF HMI WEB :
http://oldweb.icpdas.com/products/Software/Soft-GRAF/soft-graf.htm
Soft-GRAF HMI Data Sheet :
http://ftp.icpdas.com/pub/cd/8000cd/napdos/isagraf/data_sheet/Soft-GRAF.pdf
Soft-GRAF HMI FAQ-131 :
http://oldweb.icpdas.com/faq/isagraf/131.htm
XP-8xx7-CE6 support motion control solution V using motion modules
XP-8xx7-CE6 support I-8094F, I-8094 and I-8092F motion modules to achieve the Motion Control, such as 2/3-axis linear interpolation, 2-axis circular interpolation, T/S-curve acceleration/deceleration and auto-homesearchK functions. Furthermore, based on the outstanding low CPU loading feature of the motion modules, several motion modules can be used on one XP-8xx7-CE6 controller at the same time and even with other I/O statuses can be monitored simultaneously. Combining with Soft-GRAF HMI, user can design the motion control easily and smartly.
Motion Data Sheet :
http://ftp.icpdas.com/pub/cd/8000cd/napdos/isagraf/data_sheet/ISaGRAF-motion.pdf
Motion FAQ-132 :
http://oldweb.icpdas.com/faq/isagraf/132.htm
Motion Free Training Course :
http://oldweb.icpdas.com/training/signup_207_c.php (Taiwan only)
Please refer to the following links for more ICP DAS ISaGRAF Products information :
ISaGRAF PAC Datasheet :
http://oldweb.icpdas.com/products/PAC/i-8000/data sheet/data sheet.htm
ISaGRAF PAC Web :
http://oldweb.icpdas.com/products/PAC/i-8000/isagraf.htm
ISaGRAF PAC Manual :
http://oldweb.icpdas.com/products/PAC/i-8000/getting_started_manual.htm
ISaGRAF PAC FAQ :
http://oldweb.icpdas.com/faq/isagraf.htm
I-8K & I-87K high profile I/O modules :
http://oldweb.icpdas.com/products/PAC/i-8000/8000_IO_modules.htm
