I-87124 ~NEW~
1 Port DeviceNet Master Slot Module




The CAN (Controller Area Network) is a serial communication protocol, and efficiently supports distributed real-time control with a very high level of security. It is an especially suit for networking "intelligent" devices as well as sensors and actuators within a system or sub-system. In CAN network, there is no addressing of subscribers or stations in the conventional sense, but instead prioritized messages are transmitted. As standalone CAN controller, I-87124 can represent an economic solution of DeviceNet application and be a DeviceNet master device in the CAN bus on the DeviceNet network. It is a "Predefined Master connection Set", and supports Group 2 only Server functions to communication with slave devices. It has a independent CAN bus communication port with 5-pin screw terminal connector, and has the ability to cover a wide range of DeviceNet applications. Besides, I-87124 uses the new CAN controller Phillips SJA1000T and transceiver 82C250/251, which provide bus arbitration, error detection with auto correction and re-transmission function. It can be installed in I-8000 or WinCon-8000 series PAC.


It is popularly applied in the industrial automation, building automation,vehicle, marine, and embedded control network. In order to expand the DeviceNet functions of ICPDAS products, I-87124 module is developed for this purpose.


  Applications

  • CAN bus communication application.
  • Industry automation
  • Industrial Machinery
  • Building Automation
  • Food & Beverage
  • Semiconductor Fabrication
  • Control system

  •

      I-87124 Architecture






      DeviceNet Features



    Common Features:

    • 3 indication LEDs (Error,Status,Bus LEDs)
    • 1KVdc isolation on CAN side.
    • Programmable Master MAC ID.
    • Programmable transfer-rate 125K, 250K, 500K.
    • Support maximum nodes up to 64
    • Support Group 2 Only Server functions
    • The maximum Fragment number is (Input/Output) up to 64
    • Support I/O Operation Mode: Poll, Bit-Strobe and Change Of State/Cyclic
    • Support Auto-scan slave device function.
    • Support on-line add device into and remove device from network.
    • Support boot-up communicate with slave devices automatically.


      Hardware Specifications

    Model
    I-87124
     Microcontroller
    80186, 80MHz
     CAN Controller
    Philips SJA1000 CAN controller
     CAN Transceiver
    Philips 82C250 CAN transceiver
     SRAM
    512K bytes
     Flash Memory
    512K bytes
     EERROM
    2K bytes
     Transmission Speed
    1 MBPS Max.
     External Clock
    16MHz
     Terminal Resister
    „X 120£[ terminal resister selected by jumper
     CAN bus interface
    ISO/IS 11898-2, 5-pin screw terminal with on-board optical isolators protection.
     Power Supply
    2W, Unregulated +10VDC to +30VDC
     Operating Temp
    -25C to 75C
     Storage Temp
    -30C to 85C
     Humidity
    5 ~ 95%
     Dimensions
    31 mm x 115 mm x 91 mm

      Software


  • Development Toolkit for I-8000/WinCon
  •


       Ordering Information



    I-87124
    1 Port Programmable DeviceNet Interface
