CAN Bus
    I-87120







    CAN Bus


    I-8000 Series















I-87120 (I-87KCAN) ~NEW~
1 Port Programmable CAN Interface
Module




CAN (Controller Area Network) is a serial bus control protocol especially suited to constrnct intelligent industry devices networks and build smart automatic control systems. It is popularly applied in the industrial automation, building automation, vehicle, marine, and embedded control network. In order to expand the CAN functions of ICPDAS products, I-87120 module is developed for this purpose. It is a kind of module, and need to be plugged into a host unit, such as I-8000 series MCU (Main Control Unit),

WinCon-8000 and LinCon-8000. I-87120 give a way to connect these ICPDAS host unit with CAN network. Owing to the features of I-8000 series MCU, WinCon-8000, WinPAC-8000 and LinCon-8000, these host units can be arranged to be a CAN converter, CAN slave device and CAN master device in a CAN network. The righr-hand-side figure shows the application architecture for I-87120 modules.

  Applications

  • DeviceNet, CANopen, CAN J1939, SDS (System Wide Network) protocol application
  • CAN bus communication application.
  • Industry automation
  • Industrial Machinery
  • Building Automation
  • Food & Beverage
  • Semiconductor Fabrication
  • Control system

  •

      I-87120 Architecture






      Features



    Common Features:

    • One CAN port expansion for I-8000 series MCU (main control unit), WinCon-8000, WinPAC-8000 and LinCon-8000.
    • 4096 records CAN message receive-buffer size.
    • 4096 records buffer size for the command from I-8000 series MCU/ WinCon-8000/WinPAC-8000/LinCon-8000 to I-87120.
    • Provide C/C++ function libraries to send and receive CAN messages.
    • Demos and utility are provided.
    • 3 indication LEDs (Rx, Tx and Err LEDs)

    CAN Port Features:

    • Support user-defined baud
    • 2500 Vrms isolation
    • Baud : 5Kbps, 10Kbps, 20Kbps, 25Kbps, 50Kbps, 100Kbps, 125Kbps, 200Kbps, 250Kbps, 500Kbps, 800Kbps, 1Mbps.


      Hardware Specifications

    Model
    I-87120
     Microcontroller
    80186, 80MHz
     CAN Controller
    Philip SJA1000 CAN controller
     CAN Transceiver
    Philip 82C250 CAN transceiver
     SRAM
    512K bytes
     Flash Memory
    512K bytes
     EERROM
    2K bytes
     Transmission Speed
    1 MBPS Max.
     External Clock
    16MHz
     Terminal Resister
    „X 120£[ terminal resister selected by jumper
     CAN bus interface
    ISO/IS 11898-2, 5-pin screw terminal with on-board optical isolators protection.
     Power Supply
    2W, Unregulated +10VDC to +30VDC
     Operating Temp
    -25C to 75C
     Storage Temp
    -30C to 85C
     Humidity
    5 ~ 95%
     Dimensions
    31 mm x 115 mm x 91 mm

      Software


  • Development Toolkit for I-8000/WinCon/LinCon/WinPAC
  • I-87120 (I-87KCAN) don't support any ISaGRAF series main control unit
  •


       Ordering Information



    I-87120 (I-87KCAN)
    Module with one programmable CAN port, I-8000/Wincon/Lincon/WinPAC CAN port library, 80186 80MHz CPU, 512K flash, 512K SRAM, 120£[ terminal resister selected by jumper.




       Download



    Libary & Demo for I-87120 user-defined firmware
    Document
    Version
    Download
    Size
    Update
    Remarks
    Library
    1.10
    66.6KB
    May-20-2008
    Demo
    1.03
    1.31MB
    May-20-2008



    Libary & Demo for I-8000 Series
    Document
    Version
    Download
    Size
    Update
    Remarks
    Library
    1.03
    3.5KB
    Aug-06-2006
    Demo
    1.00
    0.16MB
    Aug-06-2006



    Libary & Demo for WinCon-8000 Series
    Document
    Version
    Download
    Size
    Update
    Remarks
    Library
    1.10
    5.04KB
    May-20-2008
    Demo
    1.10
    229KB
    May-20-2008



    Libary & Demo for WinPAC-8000 Series
    Document
    Version
    Download
    Size
    Update
    Remarks
    Library
    1.10
    5.15KB
    May-20-2008
    Demo
    1.10
    234KB
    May-20-2008




    Libary & Demo for LinCon-8000 Series

    Document
    Version
    Download
    Size
    Update
    Remarks
    Library
    1.03
    14.5KB
    Aug-06-2006

    Demo
    1.00
    0.12MB
    Aug-06-2006
