I-7540D ~NEW~
CAN to Ethernet Gateway |
|
|
|
|
|
|
|
| |
|
|
| |
Internet communications using TCP/IP is increasing in the industrial sector. Using Ethernet for network in industrial area is appealing because the required cabling is already installed. The CAN-Ethernet Gateway from ICP DAS is a solution that enables CAN networks to be coupled together over the Internet/Ethernet, whereby remote monitoring and control is possible. The CAN-Ethernet Gateway controls networked communication and makes a transparent CAN-based application interface available to the user.
The device supports a transparent, protocol-independent transfer of the CAN messages, thus allowing its implementation into a wide range of possible applications. Furthermore, the CAN-Ethernet Gateway can be used with various higher layer CAN protocols (e.g. CANopen, DeviceNet or other proprietary protocols). The following figure shows the application architecture for CAN-Ethernet Gateway .
Furthermore, I-7540D also can be used as Ethernet to CAN/RS-232/485 Device Server. The Device Server is an appliance that network enables any device with a serial communication port. By virtue of its independent operating system, protocol independence, small size and flexibility, Device servers are able to meet the demand of virtually any network-enable application. Most devices don't have network ports. I-7540D allows those devices to become connected to the network.
|
|
|
|
| |
|
|
| |
•Factory Automation
•Building Automation
•Home Automation
•Control System
•Monitor System
•Vehicle Automation |
 |
|
| |
|
| |
|
|
| |
|
|
| |
The VxComm technology can be used to simulate COM/CAN ports of the I-7540D to become a COM port of PC . With the help of VxComm driver, users can access the remote COM/CAN ports of the I-7540 just as them would access the PC's COM port. The block diagram of data processes in I-7540D is given as follows: |
 |
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
- 80186-80 Embedded CPU, or compatible
- Ethernet Protocols, TCP,UDP,IP,ICMP,ARP
- 10/100 Base-TX Ethernet Controller
- Reloadable Operating Software
- Message transmitted by using TCP/IP protocol
- Diagnostics
- COM driver support interrupt & 1K QUEUE Input & Output buffer
- Support one RS-232 port, one RS-485 port and one CAN port
- 2500Vrms photo-isolation protection on CAN side.
- Jumper select 120Ω terminator resistor for CAN channel
- Phillip 82C 250/251CAN Transceiver
- Support both CAN specification 2.0A and 2.0B.
- Max transmission speed up to 1M bps for CAN and 115.2K bps for RS-232 & RS-485
- Max transmission distance of CAN over 1000m (follow CAN specification)
- Built-in self-tuner ASIC controller on RS-485 port
- 7-segment LED display.
- Software configurable CAN and RS-232 communication parameters
- Firmware updated from COM1 or Ethernet port
- Support Web Configuration
- Support max 25 Ethernet clients connection
- Support for Virtual COM technology
|
| |
|
|
| |
|
-
IP 、 Gateway 、 Mask configuration
-
CAN bus Baud rate configuration
-
CAN BTR0 and BTR1 configuration
-
CAN acceptance filter configuration
-
CAN 2.0A or 2.0B specific selection
-
Error code Responded selection
-
Easy test to transmit/receive CAN messages
|
|
| |
| |
|
|
| |
|
|
| |
|
|
| |
The test is the performance which transfer 8 bytes data frame from CAN to Ethernet. |
CAN setting |
Transfer frames |
Transfer time(ms) |
Ethernet setting |
Receive frames |
Receive time (ms) |
The max frames/sec |
Data<8 byes/frme |
command length |
2.0A 1Mbps |
1,000,000 |
619,290 |
10M |
1,000,000 |
619,303 |
1614 |
>=1614 |
22 B |
2.0A 1Mbps |
1,000,000 |
619,831 |
100M |
1,000,000 |
619,871 |
1613 |
>=1613 |
22 B |
2.0B 1Mbps |
1,000,000 |
660,530 |
10M |
1,000,000 |
660,690 |
1513 |
>=1513 |
27 B |
2.0B 1Mbps |
1,000,000 |
662,432 |
100M |
1,000,000 |
662,513 |
1509 |
>=1509 |
27 B |
The test is the performance which transfer 8 bytes data frame from Ethernet to CAN. |
CAN setting |
Transfer frames |
Transfer time (ms) |
Ethernet setting |
Receive frames |
Receive time (ms) |
The max frames/sec |
Data<8 byes/frame |
command length |
2.0A 1Mbps |
1,000,000 |
535,099 |
10M |
1,000,000 |
1868 |
1868 |
>=1868 |
22 B |
2.0A 1Mbps |
1,000,000 |
535,280 |
100M |
1,000,000 |
1867 |
1867 |
>=1867 |
22 B |
2.0B 1Mbps |
1,000,000 |
562,969 |
10M |
1,000,000 |
563,202 |
1775 |
>=1775 |
27 B |
2.0B 1Mbps |
1,000,000 |
563,170 |
100M |
1,000,000 |
563,395 |
1774 |
>=1774 |
27 B |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
CPU |
| CPU |
80186, 80MHz or compatible |
SRAM |
512K Bytes |
Flash |
512K Bytes |
EEPROM |
16K Bytes |
NVRAM |
31 Bytes (battery backup, data valid up to 10 year) |
RTC (Real Time Clock) |
Yes |
64-bit Hardware Serial Number |
Yes |
Built-in Watchdog Timer |
Yes |
Communication Interface |
COM1 |
RS-232 (TXD, RXD, RTS, CTS, GND) |
COM2 |
RS-485 (D2+, D2-) |
CAN |
One CAN port with two CAN bus connector interfaces (CAN_H, CAN_L) |
Ethernet Port |
10/100Base-TX Ethernet Controller
(Auto-negotiating, Auto_MDIX, LED indicator) |
COM Port Formats |
Data bit |
7, 8 |
Parity |
Even, Odd, None |
Stop bit |
1 |
Baud-rate |
115.2Kbps max. |
CAN Port Formats |
CAN Controller |
Phillips SJA1000T CAN Controller |
CAN Transceiver |
Phillips 82C250 CAN Transceiver |
Isolated |
2500Vrms on CAN side |
Baud-rate |
1Mbps max. |
Dimensions |
I-7540D |
122 x 72 x 33 mm |
Operating Environment |
Operating Temperature |
-25°C to +75°C |
Storage Temperature |
-40°C to +80°C |
Power |
Protection |
Power reverse polarity protection |
Frame Ground for ESD Protection |
Yes |
Required Supply Voltage |
+10 to +30VDC (non-regulated) |
|
2.5W |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
I-7540D
|
Internet communication controller with one CAN bus, one RS-232, one RS-485 and one Ethernet
|
I-7540D CR
|
Internet communication controller with one CAN bus, one RS-232, one RS-485 and one Ethernet (RoHS)
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
wall-plug power Adapter/ 110VAC, 60Hz, 3.6W
|
|
wall-plug power Adapter/ 220VAC, 50Hz, 3.6W
|
|
|
| |
|
|
| |
|
|
|
|
