| Analog Output |
| Output Channels |
4 |
| Output Type |
0 ~ +5 V |
| Resolution |
12-bit |
| Output Capacity |
20mA |
| Isolation Voltage |
Non-isolation |
| Digital Output |
| Output Channels |
4 |
| Output Type |
Open-Collector (NPN) |
| Load Voltage |
+30VDC, Max |
| Load Current |
100mA, Max |
| Isolation Voltage |
Non-isolation |
| Other specifications |
| Dimensions |
64 mm x 38 mm |
| Power requirement |
+5VDC |
| Environment |
| Operating Temperature |
-25 ~ +75 ℃ |
| Storage Temperature |
-40 ~ +80 ℃ |
| Relative Humidity |
5% to 90% Non-condensing |
|
|
