X300
X300
(For I-7188XC)
Analog Output
Output Channels
2
Output Type
0~4.095V
Resolution
12-bit
Output Capacity
5mA
Isolation Voltage
Non-isolation
Other specifications
Dimensions
64 mm x 32 mm
Power requirement
+5VDC
Environment
Environment with I-7188XC or μpac-7186 series Casing
Operating Temperature : -25 ~ +75 ℃
Storage Temperature : -40 ~ +80 ℃
Relative Humidity : 5% to 90% Non-condensing
back
X300
2-channel D/A (0~4.095V)
