~NEW~ |
|
| |
|
|
ANT-421-01
Quad-band 2G GSM/GPRS and Tri-band 3G WCDMA External Antenna. |
| |
|
|
|
| |
|
|
|
|
|
|
|
|
| |
|
|
| |
|
|
| |
ANT-421-01 is a Quad-band 2G GSM/GPRS and Tri-band 3G WCDMA External Antenna. |
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
- Quad-band (850/900/1800/1900 MHz) 2G GSM/GPRS Antenna
- Tri-band (850/1900/2100 MHz) 3G WCDMA Antenna
- Magnetic Disk Base
- SMA Male (Plug)
- Omni-Directional
|
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
| Frequency |
824~960MHz & 1710~2170 MHz |
| V.S.W.R. |
< 3.0 @ 824~960MHz
< 3.0 @ 1710~2170 MHz |
| Gain |
1.0 ¡Ó 0.7 dBi @ 830 MHz
0.5 ¡Ó 0.7 dBi @ 1730 MHz |
| Operating Temperature |
- 30 ¢XC ~ + 85 ¢XC |
|
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
| Connector Type |
SMA Male (Plug) |
| Material of Radiator |
Steel |
| Material of Coaxial Cable |
RG-174 Cable // 3000 mm |
|
|
| |
|
|
| |
 |
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
| ANT-421-01 |
Quad-band 2G GSM/GPRS and Tri-band 3G WCDMA External Antenna. |
|
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
| 3S009 |
RG58A/U cable, 10 meter long SMA male to SMA female |
|
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
