Model: DP-1200
DP-1200
24V/5A Power supply






  • With built in PFC
  • 90% efficiency
  • 60% power boost ability
  • 23V to 28V adjustable range






Input voltage : 85Vac to 264Vac
Input current : <1.6A @ 115Vac, <0.8A @230Vac
Input frequency : 47Hz to 63Hz
Inrush current (cold start)
< 15A at 115Vac
< 30A at 230Vac
Outputs
MODEL NO. DP-1200
OUTPUT RAIL +24V
LOAD

MIN.

0A

RATED

5A

MAX.

6A

VOLTAGE ACCURACY ¡Ó2%
RIPPLE NOISE <50mVpp
LINE REG. ¡Ó0.1%
LOAD REG. ¡Ó0.5%
Efficiency : 90% typical at 230Vac
Hold up time : longer than 20ms at 115Vac
Over voltage protection : latch off
Over load protection : auto recovery
Short circuit protection : auto recovery
Cooling : free air convection
EMI standard : FCC docket 20780 curve "B" EN55022 "B", EN61000-3-2 class D
Safety : UL 1950, UL 508 CSA 22.2 No. 950-M90 EN 60 950
Power on indicator : Green light on the panel
Connectors: AC & DC Connector : Terminal blocks (suitable wire 26~10AWG)
Hook : For standard symmetrical 35mm DIN-rail






  • Operating temperature : -10¢XC to +70¢XC (derating: typ. 3W/K > 60¢XC)
  • Storage temperature : -25¢XC to +85¢XC
  • Dimensions : 65 mm x 125 mm x 103 mm






  1. Each output can provide up to max. load separately when the power supply starts up. To exceed the max. output power continuously is not allowed.
  2. At factory,in 60%rated load condition,each output is checked to be within voltage accuracy.
  3. Line regulation is defined by changing +-10% of input voltage from nominal line at rated load.
  4. Load regulation is defined by changing +-40% of measured output load from 60%rated load at another output set to 60%rated load.
  5. Ripple &noise is measured by using 15MHz bandwidth limited oscilloscope and terminated each output with a 0.47uF capacitor at rated load and nominal line.
  6. Hold up time is measured from the end of the last charging pulse to the time which the main output drops down to low limit of main output at rated load and nominal line.
  7. Efficiency is measured at rated load and nominal line.
