I-7018Z is specifically designed for thermocouple input. With its innovative design, I-7018Z can measure with thermocouple as accurately as HP’s multi-meter. Customers all value it high. Apart from thermocouple measurement, I-7018Z can also measure other analog input signals, like current and voltage. I-7018Z is a cost-effective way for usual applications, because ten of its input channels can individually be connected with different kinds of analog input in one time. I-7018Z has over-voltage protection (240V), open wire detection for thermocouple and current (4~20mA) and qualification for 4KV ESD.

Features of I-7018Z :

10 channels, thermocouple input, voltage input(+/-15mV to +/-2.5V), current input(4~20mA, 0-20mA and +/-20mA), over-voltage protection (240V), 4KV ESD.

I-7017Z has ten channels (differential) for analog input measurement, and meanwhile, by software setting, it can become 20 channels (single-ended). I-7017Z uses jumper to set the measurement for current and voltage, and all of its channels could individually be connected with different kinds of analog input in one time. Users can choose the sampling rate from 10Hz or 60Hz. I-7017Z has over-voltage protection (240V), open wire detection for current (4~20mA) and qualification for 4KV ESD.

Features of I-7017Z :

10 channels, voltage input(+/-150mV to +/-10V), current input(4~20mA, 0-20mA and +/-20mA), over-voltage protection (240V), 4KV ESD.

I-7017R-A5 8 channels, high-voltage input and high protection

I-7017R-A5 is specially designed for high-voltage input. It has 8 channels and users can choose the sampling rate from 10Hz and 50Hz. I-7017R-A5 both has over-voltage protection (+/-200V) and qualification for 4KV ESD. For users’ safety, ICP DAS offers a cover surrounding the channels to prevent hands from getting directly in touch with those.

Features of I-7017R-A5 :

8 channels, voltage input(+/-50V and +/-150V), over-voltage protection (+/-200V), 4KV ESD.

I-7015P 6 channels and RTD input

I-7015P is specifically designed for long-distance RTD measurement. I-7015P can do automatic compensation for three-wire RTD so that it can measure right regardless of the length of wires. Therefore, it is quite fit for applications to long-distance RTD measurement. I-7015P offers 6 channels, each of which could be connected with different kinds of RTD. Also, I-7015P has qualification for 4KV ESD.

Features of I-7015P :

6 channels, RTD input(Pt100,Pt1000,Ni120,Cu100 and Cu1000), 4KV ESD.

I-7000 family has been much more complete than ever by the efforts ICP DAS has constantly done for years. The production line includes analog input/output, digital input/output, and timer/counter. Somehow, ICP DAS realizes that there are still much we can do for our costumers; hence, a lot of new members in I-7000 family keep waiting in line for debut. At this time, we release the products with not only new functions but also protection, all of which are qualified for 4KV ESD.

For I-7000 family, please see the following link:

For applications to Modbus protocol, ICP DAS offers M-7000 family.
