USB-4018HS-16
16-Channel High Speed Thermocouple Measurement USB I/O Module
Features
• 16-Channel Analog Inputs
• High Speed Thermocouple Measurement
• USB 2.0 Full-Speed (12 Mbps)
• No external power supply (USB Bus Powered)
• LED Indicate the Power status
• Lockable USB cable
• 3000 VDC intra-module isolation
• High Speed Thermocouple Measurement
• USB 2.0 Full-Speed (12 Mbps)
• No external power supply (USB Bus Powered)
• LED Indicate the Power status
• Lockable USB cable
• 3000 VDC intra-module isolation
Introduction
The USB-4000 series provided by ICP DAS is a new solution for data acquisition. It provides easy USB plug-and-play operation and equips accurate measurement for all kinds of automation applications. Compared with the traditional PC-based cards like PCI, PC/104 and ISA cards, users can achieve data acquisition easier and quicker with USB-4000 series. The USB-4018 series is an 8 / 16-channel high speed thermocouple measurement module and supports thermocouple devices with J, K, T, E, R, S, B, N, C, L, M and LDIN43710 types. The USB-4000 series also feature intra-module isolation. The USB-4018 series provides extremely accurate thermocouple measurement and automatically cold-junction compensation for each channel. Besides, through USB-4000 series Utility, users can configure and test USB-4000 series directly and easily without any coding.
Applications
| • SMD assembly manufacturing | • PC board manufacturing |
| • Footwear manufacturing | • Pharmaceutical industry |
| • Any temperature measurement required industries | • Food industry |
Ordering Information
| PRODUCT SERIES | DESCRIPTION | QNT. | INQUIRY |
|---|---|---|---|
This combination include other products.
Similar Products
| CPU Module | |
|---|---|
| Watchdog Timer | 1 Hardware watchdog (1.6 second) 1 Software watchdog (Programmable) |
| Isolation | |
|---|---|
| Intra-module Isolation | Yes, 3000 VDC |
| LED Indicators | |
|---|---|
| Status | PWR : Yellow for normal operation Error : Red for error indicator |
| Analog Input | |
|---|---|
| Channels | 16 |
| Type | Thermocouple : J, K, T, E, R, S, B, N, C, L, M, L(DIN43710) |
| Resolution | 0.1ºC |
| Accuracy | ±0.5ºC |
| Sampling Rate | 100Hz (each channel) |
| USB | |
|---|---|
| Specification | USB 2.0 Full-Speed (12Mbps) |
| Driver | USB Virtual COM port driver for Windows 7/10/11 Linux OS (Kernel 2.4 or later version) |
| Protocol | Modbus RTU |
| Power | |
|---|---|
| Consumption | 0.18 W Max. |
| Mechanical | |
|---|---|
| Dimensions (mm) | 113 x 169 x 54 (W x L x H) |
| Environment | |
|---|---|
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -40 ~ +85 °C |
| Humidity | 10 ~ 95% RH, Non-condensing |
