RPM-D24
Redundant Power Module with 24 VDC input
Features
- Power redundancy
- Over-voltage protection (5A Fuse)
- Built-in LED power indicator
Introduction
The RPM-D24 is a power supply module for the RIO-98x0 system with the following features:
- 24 VDC Power Input: Provides stable power supply for communication modules and I/O modules of RIO-98x0 system.
- Over-voltage Protection: Built-in 5A fuse protects the system from over-voltage damage.
- LED Indicator: Indicates the status of the external 24 VDC voltage supply, allowing users to monitor whether the power supply is normal or not.
The module supports dual design, even if a single power module fails, the RIO-98x0 can still run stably, which further enhances the reliability of the system.
Applications
- Building Automation
- Factory Automation
- Machine Automation
- Remote Maintenance
- Remote Diagnosis
- Testing Equipment
Ordering Information
| PRODUCT SERIES | DESCRIPTION | QNT. | INQUIRY |
|---|---|---|---|
This combination include other products.
Similar Products
| EMS Protection | |
|---|---|
| EFT (IEC 61000-4-4) | Yes |
| ESD (IEC 61000-4-2) | Yes |
| LED Indicators | |
|---|---|
| Status | 1 x Power |
| Power | |
|---|---|
| Reverse Polarity Protection | Yes |
| Consumption | 0.24W (0.01A@24VDC) |
| Mechanical | |
|---|---|
| Dimensions (mm) | 33 x 129 x 130 |
| Environment | |
|---|---|
| Operating Temperature | -25 °C ~ +70 °C |
| Humidity | 5 ~ 95% RH, Non-condensing |
