CPU Module
CPU	80 MHz internal microprocessor
EEPROM	16 KB, retention > 40 years. 1,000,000 erase/write cycles
Flash	512KB
NVRAM	31 bytes, battery backup, data valid up to 10 years
SRAM	512KB
Real Time Clock	Provide seconds, minutes, hours, day of week/month, month and year
Watchdog Timer	Yes

Display
Backlight Life	Expected life is more than 100,000 hours under normal operation
Active Display Area (mm)	80.61 mm x 14.37 mm (W x H)

Lead Acid Battery Charger
Battery Voltage	12V Lead-Acid Battery
Charging Voltage	Voltage of Power Input must be over +16V
Low Voltage Protect	Low Voltage disconnect = 11.1V / Low Voltage reconnect = 12.6V

LED Indicators
Status	1 x System 1 x 3G 1 x GPS 1 x Charging / Fault

2G System
Data Transmission Rate	GPRS Downlink transfer: Max. 85.6 kbps; Uplink transfer: Max. 42.8kbps
Frequency Band	850/900/1800/1900 MHz
Coding Schemes	CS 1, CS 2,CS 3,CS 4
GPRS Multi-slot	GPRS class 10/8; GPRS station class B
Power Class	Class 4 (2 W @ 850/900 MHz) Class 1 (1 W @ 1800/1900 MHz)
SMS Format	Sending: UCS2/7bits Receiving: UCS2/7bits

3G System
Data Transmission Rate	DC-HSPA+ Downlink transfer: Max. 42 Mbps; Uplink transfer: Max. 5.76Mbps TD-SCDMA Download: Max. 4.2 Mbps; Upload: Max 2.2Mbps CDMA2000 EVDO Download: Max. 14.7 Mbps; Upload: Max 5.4Mbps
Frequency Band	WCDMA 850/900/1900/2100 MHz
Power Class	Class 3 (24dBm+1/-3dB) for WCDMA
SMS Mode	MT, MO, CB, Text and PDU mode

4G System
Data Transmission Rate	LTE Downlink transfer: Max. 100 Mbps; Uplink transfer: Max. 50 Mbps
Frequency Band	FDD LTE: B1/B2/B3/B4/B5/B7/B8/B28 TDD LTE: B40

GPS/GNSS
Acquisition Time	Hot start (Open Sky) = 2 s(typical) Cold start (Open Sky) = 36 s(typical)
Protocol	NMEA 0183 version 3.01
Sensitivity	Tracking = up to -159 dBm (with external LNA) Cold start = up to -146 dBm (with external LNA)
Support Channels	32

Analog Input
Channels	8
Type	Current
Range	0 ~ 20 mA
Resolution	12 - bit
Accuracy	+/- 2 LSB (+/- 0.0097 mA)
Sampling Rate	1 KHz max. (Read one channel).
Isolation	2500Vrms 3000Dc to DC

Digital Input
Channels	3
Type	Dry Contact
ON Voltage Level	Close to GND
OFF Voltage Level	Open
Isolation	Non-isolated

Digital Output
Channels	3
Type	Open Collector
Sink/Source (NPN/PNP)	Sink (NPN)
Load Voltage	+30 VDC max.
Load Current	100 mA max.
Isolation	Non-isolated

Relay Output
Channels	1
Contact Rating	Form C: 2A @ 30 VDC 0.25 A @ 250 VAC
Mechanical Endurance	typ. 10^8 operations

Ethernet
Ports	1 x RJ-45, 10/100Base-T(X)

COM Ports
Ports	1 x RS-232 1 x RS-485

Power
Consumption	Deep Sleep: < 10 mA @ 12VDC; Deep Sleep(With LCD): < 11 mA @ 12VDC; Sleep: < 15 mA@12VDC; Idle: 90 mA @ 24 VDC; Data Link: 150 ~ 400 mA (peak) @ 24 VDC

Mechanical
Casing	Metal
Dimensions (mm)	47 x 142 x 168 (W x L x H)
Panel Cut-Out (mm)	93 mm x 70 mm x 1.6 mm (W x H x T)
Installation	DIN-Rall and Wall mount

Environment
Operating Temperature	-15 ~ +55 °C
Storage Temperature	-20 ~ +70 °C
Humidity	5~90% RH, non-condensing
