BRK-2841M
IIoT MQTT Communication Server with Quad-core ARM CPU and 2 Ethernet Ports
Features
- High-Performance MQTT Broker Service
- Automated Failover
- Intuitive Web UI Remote Management
- Diverse Database Integration
- Data Retransmission & Auto-Backfill
Introduction
BRK Series is a Communication Server that specially provides Broker function of MQTT protocol for MQTT message distribution and concentrator in M2M and Industrial Internet of Things environments. The BRK Series is compatible with the MQTT version V.3.1, V.3.1.1 and V.5.0 protocol. It supports many functions such as QoS message quality mechanism, retains mechanism, identity authentication, communication encryption, last message (Last Will), and bridge. The method of Web UI settings can quickly set up BRK functions. This reduce the burden of setting up the broker by user oneself and the maintenance cost. Besides, BRK Series provides Bridge, Cluster, Load Balancer, and High Availability functions. By forming multiple BRK Series a group to a better Redundancy system can prevent field systems from stopping services due to hardware or network failures
Applications
• Bridge Architecture Application
• Redundancy Architecture Application
• Cluster Architecture Application
• Plastic Injection Molding Machine Monitoring Applications
Click to view the Applications of IIoT MQTT Solution.
• Redundancy Architecture Application
• Cluster Architecture Application
• Plastic Injection Molding Machine Monitoring Applications
Click to view the Applications of IIoT MQTT Solution.
Ordering Information
| PRODUCT SERIES | DESCRIPTION | QNT. | INQUIRY |
|---|---|---|---|
This combination include other products.
Similar Products
| Software | |
|---|---|
| OS | Linux Kernel 4.1.15 |
| Protocol | MQTT |
| Function | · High-Performance MQTT Broker Service Supports all MQTT versions, encryption, and clustering for secure, stable high-volume data transmission. · Automated Failover Hot-standby mechanism enables seamless 10-second backup switching, ensuring zero service disruption. · Intuitive Web UI Remote Management Browser-based configuration requires no software installation, drastically reducing maintenance costs. · Diverse Database Integration Directly writes to mainstream databases (like MySQL) to effortlessly bridge OT devices and IT platforms. · Data Retransmission & Auto-Backfill Buffers data to an SD card (up to 14 days) during outages and auto-backfills upon reconnection for zero data loss. |
| Main Unit | |
|---|---|
| CPU | Quad-core ARM CPU, 1.6 GHz/Core |
| System Memory | DDR4 SDRAM 2 GB |
| Storage | eMMC 8 GB |
| Non-Volatile Memory | FRAM 64 KB, MRAM 128 KB |
| LED Indicators | |
|---|---|
| Status | 1 x PWR, 1 x RUN, 3 x User Defined LED |
| HMI | |
|---|---|
| Rotary Switch | 1 x 10 Position (0~9) |
| Ethernet | |
|---|---|
| Ports | RJ-45 x 2, 10/100/1000 Base-TX (Auto-negotiating, Auto MDI/MDI-X) |
| USB | |
|---|---|
| Connector | 2 x 2.0 host |
| Power | |
|---|---|
| Input Range | +12 ~ +48 VDC |
| Consumption | 10 W |
| Mechanical | |
|---|---|
| Casing | Metal |
| Dimensions (mm) | 35 x 167 x 119 (WxLxH) |
| Installation | DIN-Rail |
| Environment | |
|---|---|
| Operating Temperature | -25〜+70℃ |
| Storage Temperature | -40〜+80℃ |
| Humidity | 10〜90% RH,Non-condensing |
