VP-1231-CE7 – ViewPAC for 5.7” touch panel (Windows Embedded Compact 7.0-based)
New Products
2017-01-17
Introduction
The VP-1231-CE7 is a WinCE7-based ViewPAC module that combines computing, I/O, and an operator interface into a single unit, and provides a perfect solution for integrating HMI, data acquisition and control in an individual PAC. The VP-1231-CE7 is equipped with a Cortex-A8 1GHz CPU, a TFT LCD, and a variety of connection ports, including a Gigabit Ethernet port, a USB port, and an RS-232/RS-485 interface. The capacity for I/O expansion is available; ICP DAS offers Ethernet and RS-485 I/O modules options for users to freely choose from. The VP-1231-CE7 is designed to operate over a wide-ambient temperature range from -20°C to 70°C, and the fan-less design offers the ultimate in reliability with no moving parts.Compared with the VP-25W1, the hardware size and the positions and numbers of the peripheral communication interface of the VP-1231-CE7are completely compatible with the VP-25W1, and the hardware can be directly upgraded. Hardware specifications include faster CPU, Gigabit Ethernet and larger RAM / Flash memory; the overall system performance is greatly improved than the previous generation.
Features:
- Cortex A8, 1GHz CPU
- Flash: 256 MB ; SDRAM: 512 MB
- CE7 (Windows Embedded Compact 7)
- Hard Real-time Capabilities
- One 10/100M/1G Ethernet network
- Two serial port (RS-232, RS-485)
- LCD Display
- 128 KB MRAM
- Wide range of I/O Expansion capabilities
- 3 I/O Slots
- Dual Watchdog
- Six Rubber Keypad
- 64-bit Hardware Serial Number
- Free eLogger HMI included
- Ultra-rugged Construction and Reliable Design
- Wide Operating Temperature Range: -20°C to +70°C
For more information about VP-1231, please visit: https://www.icpdas.com/en/product/VP-1231-CE7
|
Specification Comparison
|
||
| Specification | VP-25W1 | VP-1231-CE7 (New) |
|---|---|---|
| OS | WinCE 5.0 | WinCE 7.0 |
| CPU | PXA270, 520 MHz | Cortex-A8, 1 GHz |
| RAM size | 128 MB | 512 MB |
| ROM size | 96 MB | 256 MB |
| Ethernet | 10/100 Base-TX | 10/100/1000 Base-TX |
| Dimension |  (WxHxD):182 mm x 125 mm x 158 mm |
 (WxHxD):182 mm x 125 mm x 158 mm |
Compared with the VP-25W1, the hardware size and the positions and numbers of the peripheral communication interface of the VP-1231-CE7 are completely compatible with the VP-25W1, and the hardware can be directly upgraded. Hardware specifications include faster CPU, Gigabit Ethernet and larger RAM / Flash memory; the overall system performance is greatly improved than the previous generation.
For more differences between VP-1231 and VP-25W1, please visit:
https://www.icpdas.com/en/product/guide+Panel__Products+ViewPAC+WinCE__ViewPAC#1023
