System
The iDCS-8000 system is a combination of power, communication within the backplane. For different combination, there will be different iDCS-8000 system. Here is the list of iDCS-8000 system. |
 |
Will be available |
 |
Available soon |
 |
Will be phased out |
|
Model |
Redundancy |
Auto Configuration |
Hot Swap |
Comm. Interface |
I/O Slot |
 |
iDCS-8830 |
| 2x FPM-D2440+2x FCM-MTCP |
 |
|
Yes |
Yes |
Yes |
Modbus/TCP |
8 |
|
| |
 |
| |
| Modules |
|
Will be available |
|
Available soon |
|
Will be phased out |
|
Type |
Model Name |
Description |
| Communication Module |
|
FCM-MTCP |
Modbus/TCP with support redundant function |
| Power Module |
|
FPM-D2440 |
24 VDC input, 35W@5V, 120W@24V, with redundant function |
| Digital |
Input |
|
F-8040 |
32-ch, dry contact, sink/source, Isolated, one COM for all DI, LED display |
| Output |
|
F-8041 |
32-ch, sink, 0.1A/channel, Isolated, one COM for all DO, LED Display |
| Analog |
Input |
|
F-8017C1 |
8-ch, 4~20mA, Isolated |
|
F-8017C2 |
16-ch, 4~20mA, Isolated |
|
F-8017CH |
8-ch, 4~20mA with HART compliant, Isolated |
|
F-8015 |
8-ch, RTD sensor Pt100, Pt1000, JPt100, Isolated |
|
F-8019 |
8-ch, Single/Duplex, universal analog input and Thermocouple
(J, K, T, E, R, S, B, N, C, L, M), Isolated |
| Output |
|
F-8028CV |
8-ch, 4~20mA, 0~20mA, 0~5V, 0~10V, +/-5V, +/-10V, Isolated |
|
F-8028CH |
8-ch, 4~20mA with HART compliant, Isolated |
| Pulse |
Input |
|
F-8084 |
8-channel High Speed Pulse Input Module, Isolated |
|
| |
| Termination Boards |
|
Will be available |
|
Available soon |
|
Will be phased out |
|
Type |
Model Name |
Description |
Supported module |
| Digital |
General |
|
DN-DIO-M |
General termination board for digital I/O |
F-8040, F-8041 |
| Input |
|
DN-DI-32DW |
32-ch, sink/source, EMS protection |
F-8040 |
| Output |
|
DN-DO-16DR-A |
16-ch (ch0~ch15), removable 6A relay output with varistor |
F-8041 |
|
DN-DO-16DR-B |
16-ch (ch16~ch31), removable 6A relay output with varistor |
F-8041(1) |
| Analog |
General |
|
DN-AIO-M |
General termination board for analog (Current/Voltage) I/O |
F-8017C1, F-8028CV,
F-8028CH |
| Input |
|
DN-AII-08 |
Termination board for current input module |
F-8017C1 |
|
DN-AIH-08 |
Termination board for HART analog input module |
F-8017CH |
|
DN-RTD-M |
Termination board for RTD module |
F-8015 |
|
DN-TC-M |
Termination board for thermocouple module |
F-8019 |
| Pulse |
Input |
|
DN-PI-M |
Termination board for pulse input module |
F-8084 |
|
| (1) The DN-DO-16DR-B cannot work standalone. It must connect to DN-DO-16DR-A when channel15~31 is used. |
| |
 |
|
| |
 |
| CA-2520D |
2m 25-pin Male-Male D-sub flat cable |
| CA-3710AM |
1m 37-pin Male-Female D-sub cable, 24AWG, UL-2464 |
| CA-3720AM |
2m 37-pin Male-Female D-sub cable, 24AWG, UL-2464 |
| CA-3730AM |
3m 37-pin Male-Female D-sub cable, 24AWG, UL-2464 |
| CA-3750AM |
5m 37-pin Male-Female D-sub cable, 24AWG, UL-2464 |
| CA-37100AM |
10m 37-pin Male-Female D-sub cable, 24AWG, UL-2464 |
|
| |
 |
| Ethernet Switch |
Industrial Ethernet Switch with DIN rail mounting |
| Power Supply |
24 VDC power supply |
| InduSoft |
A powerful, integrated collection of automation tools to develop modern Human Machine Interfaces (HMI) |
| ISaGRAF |
A PLC-like SoftLogic (IEC 61131-3) standard software |
|
| |
|
| |
|
|
|
|
