ANT-421-01
3 m Quad-band 2G GSM/GPRS and Tri-band 3G WCDMA External Antenna



Model: ANT-421-01

  • Quad-band (850/900/1800/1900 MHz) 2G GSM/GPRS Antenna
  • Tri-band (850/1900/2100 MHz) 3G WCDMA Antenna
  • Magnetic Disk Base
  • SMA Male (Plug)
  • Omni-Directional

ANT-421-01 is a Quad-band 2G GSM/GPRS and Tri-band 3G WCDMA External Antenna.

Frequency 824~960MHz & 1710~2170 MHz
V.S.W.R. < 3.0 @ 824~960MHz
< 3.0 @ 1710~2170 MHz
Gain 1.0 ± 0.7 dBi @ 830 MHz
0.5 ± 0.7 dBi @ 1730 MHz
Operating Temperature - 30 °C ~ + 85 °C

Connector Type SMA Male (Plug)
Material of Radiator Steel
Material of Coaxial Cable RG-174 Cable // 3000 mm

ANT-421-01 3 m Quad-band 2G GSM/GPRS and Tri-band 3G WCDMA External Antenna

3S009 RG58A/U cable, 10 meter long SMA male to SMA female
