ANT-115-03
5 m GPS Active External Antenna

Model: ANT-115-03


1575.42 MHz GPS Antenna Magnet mount SMA Male (Plug)

ANT-115-03 is an External GPS Active Antenna.

Frequency	1575.42 ± 1.023 MHz
Polarization	RHCP
V.S.W.R.	2.0 (Max.)
Impedance	50 Ohms ±5Ω
Gain	90° : 2.0 dBi Min. 20° : -5.0 dBi Min. Mounted on the 60mm*60mm ground plane.
Operating Temperature	-30°C ~ + 80°C
Relative Humidity	40% ~ 95%

Connector Type	SMA Male (Plug)
Cable	RG-174, 5 m
Mounting	Magnet mount
Horizontal Pulling Force of Magnet	1.5 Kg Min.
Weight	105 g
Water Proof	Deep into water 50cm, 30 Min.
