DP-660
24V/2.5A , 5V/0.5A Dual output Power supply



Model: DP-660


DP-660 is a 65 watts,universal input switching mode power supply.

It is with 24V/5V output options. DP-660 is intended for power device like motor or solenoid application.Build in +5V 3T-regulator for DP-660 is for if there is a logical control circuit.

  • Input voltage: 85 VAC ~ 270 VAC
  • Input frequency: 47 Hz ~ 63 Hz
  • Inrush current (Cold start):
    less than 30A at 115 VAC
    less than 60A at 230 VAC
  • DC Outputs:
    +24 V/2.5 A
    +5 V/0.5 A
  • Efficiency: higher than 70% at rated load and 115 VAC
  • Holdup time: 16ms at rated load and 115 VAC
  • Over voltage protection: hiccup mode
  • Short circuit protection: latch off
  • Over voltage protection: latch off
  • Operating temperature: 0 ~ 50 °C
  • Cooling: free air convection
  • Storage temperature: -40 °C ~ +85 °C

DP-660 24V/2.5A , 5V/0.5A Dual Output Power Supply
