End of Life Notification for TPD-432F
- EOL notification date: 2017/12/12
Phased out model: TPD-432F
Last Order Date: Subject to availability (limited in quantity while stocks last)
Dear Partners,
ICP DAS hereby formally announces the manufacturing discontinue and End of Life (EOL) of TPD-432F.
Within the effective warranty period, ICP DAS is committed to continue providing comprehensive after-sales service and technical support.
● Reason for termination: Phase out of MCU
● Suggested replacement device: TPD-432F-H
- Status: Available
- Please refer to the following table for cross reference information. -
Model NameTPD-432FTPD-432F-HProduct StatusPhased outAvailableCPU32-bit RISC CPU32-bit RISC CPUMiniOS8Yes (update required)-Memory Expansion16 MB SDRAM/8 MB Flash16 MB SDRAM/16 MB FlashReal Time Clock (RTC)YesYesBuzzerYesYesRotary Switch (0~9)YesYesLCD4.3 TFT (Resolution 480 x 272, 65536 colors)4.3 TFT (Resolution 480 x 272, 65536 colors)Serial PortCOM1: RS-485
COM2: RS-485COM1: RS-485
COM2: RS-485Firmware updatesUSB 1.1 ClientUSB 1.1 ClientPowered from Terminal Block+10 ~ +30 VDC+12 ~ +48 VDCReset ButtonYesYes - Migrating projects from TPD-432F to TPD-432F-H:
1. Open original project by using HMIWorks v2.10.24 or last version.
2. Click the HMIWorks menu item "Project/Project Configuration". - 3. Click the "General" page and select the “TPD” option.
4. Change the "TouchPAD Type" to TPD-432F-H. - If your original project uses Ladder program, and is created by HMIWorks v2.09.09 or older versions, please follow the steps 5 - 6 to disable the new Ladder mode.
New ladder mode: The Coil-Set and Coil-Reset change the coil state and lock it (industrial standard) until reset or set. Other coil operations will not unlock or change it.
Old ladder mode: There is no lock feature.
5. Click the "Others" page.
6. Unchecked the "Use New Ladder Implementation” item in the “Ladder” pane.
7. Click "OK" button. - 8. Click the HMIWorks menu item "Run/Build (Render, Compile)" to rebuild project or press F5.
-
For more information, please visit the link below:
http://www.icpdas.com/root/product/solutions/hmi_touch_monitor/touchpad/tpd-43xf-h.html
