End of Life Notification for TPD-280U
- EOL notification date: 2017/08/23
Phased out model: TPD-280U
Last Order Date: 2017/08/31
Dear Partners,
ICP DAS hereby formally announces the manufacturing discontinue and End of Life (EOL) of TPD-280U.
Within the effective warranty period, ICP DAS is committed to continue providing comprehensive after-sales service and technical support.
● Reason for termination: Phase out of MCU
● Suggested replacement device: TPD-280U-H
- Status: Available
- Please refer to the following table for cross reference information. -
Model NameTPD-280UTPD-280U-HProduct StatusPhased outAvailableCPU32-bit RISC CPU32-bit RISC CPUMemory Expansion16 MB SDRAM/8 MB Flash16 MB SDRAM/16 MB FlashReal Time Clock (RTC)YesYesBuzzerYesYesRotary Switch (0~9)YesYesLCD2.8 TFT
(Resolution 240 x 320 x 16)2.8 TFT
(Resolution 240 x 320 x 16)Serial PortRS-485 (including Self-Tuner)RS-485 (including Self-Tuner)Firmware updatesUSB 1.1 ClientUSB 1.1 ClientEthernet--Powered from PoE--Reset ButtonYesYes - Migrate projects from TPD-280U to TPD-280U-H:
1. Open original project by using HMIWorks v2.10.11 or last version.
2. Click the HMIWorks menu item "HMI/Project Configuration". - 3. Click the "General" page.
4. Change the "TouchPAD Type" to TPD-280U-H.
5. Click "OK" button. - If your original project uses Ladder program, and is created by HMIWorks v2.09.09 or older versions, please follow the steps 6 - 8 to disable the new Ladder mode.
New ladder mode: The Coil-Set and Coil-Reset change the coil state and lock it (industrial standard) until reset or set. Other coil operations will not unlock or change it.
Old ladder mode: There is no lock feature.
6. Click the "Others" page.
7. Unchecked the "Use New Ladder Implementation” item in the “Ladder” pane.
8. Click "OK" button. - 9. Click the HMIWorks menu item "Run(Build & Download)/Build & Render" to rebuild project or press F5.
-
For more information, please visit the link below:
http://www.icpdas.com/root/product/solutions/hmi_touch_monitor/touchpad/tpd-280-h.html
