End of Life Notification for TPD-283U
- EOL notification date: 2017/04/26
Phased out model: TPD-283U
Last Order Date: 2017/08/31
Dear Partners,
ICP DAS hereby formally announces the manufacturing discontinue and End of Life (EOL) of TPD-283U.
Within the effective warranty period, ICP DAS is committed to continue providing comprehensive after-sales service and technical support.
● Reason for termination: Phase out of MCU
● Suggested replacement device: TPD-283U-H
- Status: Available
- Please refer to the following table for cross reference information. -
Model NameTPD-283UTPD-283U-HProduct StatusPhased outAvailableCPU32-bit RISC CPU32-bit RISC CPUMemory Expansion16 MB SDRAM/8 MB Flash16 MB SDRAM/16 MB FlashReal Time Clock (RTC)YesYesBuzzerYesYesRotary Switch (0~9)YesYesLCD2.8 TFT
(Resolution 240 x 320 x 16)2.8 TFT
(Resolution 240 x 320 x 16)Serial PortRS-485 (including Self-Tuner)RS-485 (including Self-Tuner)Firmware updatesUSB 1.1 ClientUSB 1.1 Client or EthernetEthernetRJ-45 x 1, 10/100 Base-TXRJ-45 x 1, 10/100 Base-TXPowered from PoEIEEE 802.3af, Class1 (48 V)IEEE 802.3af, Class1 (48 V)Reset ButtonYesYes - Migrate projects from TPD-283U to TPD-283U-H:
1. Open original project by using HMIWorks v2.10.11 or last version.
2. Click the HMIWorks menu item "HMI/Project Configuration". - 3. Click the "General" page.
4. Change the "TouchPAD Type" to TPD-283U-H. - 5. Click "OK" button.
6. Click the HMIWorks menu item "Run(Build & Download)/Build & Render" to rebuild project or press F5. -
For more information, please visit the link below:
http://www.icpdas.com/root/product/solutions/hmi_touch_monitor/touchpad/tpd-280-h.html
