- Features¡G
802.11b compliant for WLAN
Site survey finds APs and ad hoc networks
802.3 compliant for wired LAN
Small and compact
Range up to 100m
- Interface¡G
System Interface:Ethernet (RJ45)
- Wireless¡G
Standard: IEEE 802.11b DSSS (2.4GHz ISM radio banc)
Data Rate: 11Mbps, 5.5Mbps, 1Mbps (Auto scaling)
Transmit Power: +15 dBm (typical)
Sensitivity
| Data Rate Sensitivity |
Modulation |
| 11Mbps-84dBm |
CCK |
| 5.5Mbps-87dBm |
CCK |
| 1Mbps-90dBm |
DBPSK |
Integrated Antenna: Internal patch antenna with diversity
- Physical Specification¡G
Dimension: 72 x 103 x25mm (L x W x D)
Weight: 250g
- Environment Specification¡G
Temperature: 0¢XC to 55¢XC
Humidity 10% to 95%, non-condensing
- Power Supply¡G
Operating Voltage 3.3V ¡Ó5% or 5.0V ¡Ó5%
Current Consumption 500mA (maximum)
- Regulatory Compliance¡G
FCC Class B, CE Mark
LED Indicators: RF activity, LAN activity, Power
SOFTWARE SUPPLIED Management utility: Client Manager Utility
WARRANTY: 2 year (limited)
- Package Contents¡G
T-316 802.11b Wireless LAN Ethernet Client CD-ROM with software and documentation
Quick installation Guide
|
|
